Cworth 500W Solar Panel for Residential and Commercial Solar Backup, Mono TOPCon 144 Cells, 22.3% Efficiency, 1000/1500VDC System Voltage, 12-Year Product Warranty (CE-500W)
⇄ Compare ♡ Save ↗ Share ⬇ Specs (CSV)
Cworth · Solar Panels

Cworth 500W Solar Panel for Residential and Commercial Solar Backup, Mono TOPCon 144 Cells, 22.3% Efficiency, 1000/1500VDC System Voltage, 12-Year Product Warranty (CE-500W)

UGX411,400
☆☆☆☆☆ No reviews yet ·Questions (0)
App price · Save UGX12,342
Sold by
Cworth Energy ✓
160 In stock
UGX411,400
Want another price?Only one shop lists this right now. Send one request and other shops reply with their prices.
Similar products from other shops
Cworth 600W Solar Panel for Residential and Commercial Solar Backup, MONO TOPCon 144 Cells, 22.3% Efficiency, 1000/1500VDC System Voltage, IP68 Junction Box, 12-Year Product Warranty (CE-600W) Cworth 600W Solar Panel for Residential and Commercial Solar Backup, M... UGX429,000 Auto Solutions plus ltd SRNE 600W Monocrystalline Solar Panel for Residential and Commercial Solar Backup with 144 Half-Cell Technology, Anti-Reflection Coated Glass, MC4 Connectors (GS600N-144M) SRNE 600W Monocrystalline Solar Panel for Residential and Commercial S... UGX396,000 Masrcorp Solar Uganda Cworth 350W Monocrystalline TOPCon Solar Panel for Residential and Commercial Solar Installations 1500V System Voltage 80-Cell 1640x992x30mm (CE-350W) Cworth 350W Monocrystalline TOPCon Solar Panel for Residential and Com... UGX290,400 Cworth Energy Cworth 200W Mono TOPCon Solar Panel for Residential and Commercial Solar Backup, 22.8V Vmp, 1000V Max System Voltage, 3.2mm Tempered Glass, 12-Year Product Warranty (CE-200W) Cworth 200W Mono TOPCon Solar Panel for Residential and Commercial Sol... UGX181,500 Cworth Energy
Ways to payAll options
Pay NowBank Transfer
Complete your system
Inverter
UGX1,146,960
Battery
UGX2,862,000
Cables, mounting and protection
UGX49,809
With this product:
Technicians who install this
View All
Swipe/scroll to see more →
Key specs
Brand Cworth Model CE-500W
Rated Power 500 W Max PV Open Circuit Voltage 48.2V
Nominal Voltage 1000/1500VDC (IEC) Product Dimensions 2279x1134x35mm
Product Weight 27.5 KG Efficiency 22.3%
Operating Temperature -40°C~+85°C Cell Type MONO TOPCon 182x182mm
Chemistry MONO TOPCon Current at Pmax (Imp) 12.3A
Current Rating 12.3 A Frame Anodized Aluminium Alloy
Front Glass 3.2mm, Anti-Reflection Coating, High Transmission, Low Iron, Tempered Glass Junction Box (IP Rating) IP68
Max. PV short circuit current 13.01A Maximum Power (Pmax) 500W (0~+5W)
Maximum Series Fuse Rating 30A Number of Cells 144 (12x12)
Output Cables (+): 500mm , (-): 500mm or Customized Length Power Tolerance 0~+3%
Short-circuit Current (Isc) 13.01A SKU SM-CAT-CWO-00879
Snow Load 5400 Pascal Temperature Coefficient of Voc -0.35%/°C
Voltage at Pmax (Vmp) 40.65V Wind Load 2400 Pascal

Notice a wrong or outdated datasheet? Help us fix it.

About this product

Overview

Cworth CE-500W is a solar panel for Uganda operating conditions. It is suitable for Residential rooftop, Commercial, Off-grid and backup, Grid-tied solar arrays. Buyers should also confirm Cell Type: MONO TOPCon 182x182mm; No. of cells: 144 (12x12); Dimensions: 2279x1134x35mm; Weight: 26-27kg, verified seller pricing, warranty terms, and installer compatibility before ordering

About this item

  • Cell Technology: Mono TOPCon 182x182mm cells with 144 half-cut cells for improved low-light performance and higher energy yield.
  • Module Efficiency: 22.3% STC efficiency, reducing the number of panels needed for a given system size.
  • Durability: 3.2mm tempered glass with anti-reflection coating, anodized aluminium frame, and IP68 junction box for long-term outdoor use.
  • Warranty: 12-year product warranty and 25-year linear power output warranty with 0.45% annual degradation.
  • Mechanical Load: Rated for 2400 Pascal wind load and 5400 Pascal snow load, suitable for various mounting conditions.
  • System Voltage: Maximum system voltage of 1000/1500VDC (IEC), compatible with standard residential and commercial inverters.

What's Included

  • 1x Cworth CE-500W solar panel
  • 1x IP68 junction box with 500mm output cables (+ and -)
  • 1x warranty card

Applications

  • Residential rooftop solar systems
  • Commercial and industrial solar installations
  • Off-grid and backup power systems
  • Grid-tied solar arrays
  • Solar water pumping systems
Ask Volta about this“Will it run my fridge and pump overnight?”
Chat with Volta
Frequently Asked Questions
What are the key specs of Cworth CE-500W in Uganda?
Cworth CE-500W is a solar panel in Uganda. Key datasheet specs include Cell Type: MONO TOPCon 182x182mm; No. of cells: 144 (12x12); Dimensions: 2279x1134x35mm; Weight: 26-27kg.
Which technical limits should installers verify for Cworth CE-500W?
Installers should verify Cell Type (MONO TOPCon 182x182mm), No. of cells (144 (12x12)), and Dimensions (2279x1134x35mm) before commissioning Cworth CE-500W.
What should buyers compare before ordering Cworth CE-500W in Uganda?
Compare verified seller price, warranty, authenticity, and after-sales support for Cworth CE-500W. Match all offers against the same datasheet values: Cell Type: MONO TOPCon 182x182mm; No. of cells: 144 (12x12); Dimensions: 2279x1134x35mm; Weight: 26-27kg.
What installation details matter most for Cworth CE-500W?
Installers should verify Weight (26-27kg), ensure the mounting or system fit matches the site, and confirm any protection or operating limits listed for Cworth CE-500W.
How should buyers judge durability or service life for Cworth CE-500W?
Durability should be judged using Front Glass (3.2mm, Anti-Reflection Coating, High Transmission, Low Iron, Tempered Glass) and Frame (Anodized Aluminium Alloy), plus the warranty term and the way the product is mounted or used.
Why is Cworth CE-500W a practical fit for local solar projects?
It is practical where the site needs Cell Type (MONO TOPCon 182x182mm), No. of cells (144 (12x12)), and Dimensions (2279x1134x35mm), because those are the model's core operating limits.
