Sosen 3.6kW Hybrid Inverter for Home and VS Sosen SSA-HL1.2~12K-P1EU 6kW Off-grid Hybrid Inver...
VS
A/B
Specifications Comparison
Spec keys are preserved from both products. We never remove a key just because the other product has no value yet.
| Feature | Sosen 3.6kW Hybrid Inverter for Home and | Sosen SSA-HL1.2~12K-P1EU 6kW Off-grid Hybrid Inver... |
|---|---|---|
| Overview | ||
| Brand | - | Sosen |
| Model | - | SSA-HL1.2~12K-P1EU |
| Battery Type | Lithium / Lead-acid | Lithium Lead-acid |
| Inverter Type | 92.7%@24V d.c. | - |
| Output | ||
| Power Factor | 1 | - |
| Rated Power | 3.6 kW | 6000 W |
| Battery | ||
| Chemistry | Lithium / Lead-acid | - |
| Solar Input | ||
| Max PV Input Power | 5 kW | - |
| Number of MPPT Trackers | 1/1 | 1 |
| MPPT Voltage Range | 40~450 V | - |
| Max PV Input Current | 18 A | - |
| Max PV Voltage (DC) | 500 V | - |
| PV Start-up Voltage | 120 V | - |
| Short Circuit Current (Isc) | 22 | - |
| AC Input | ||
| Rated AC Input/Output Active Power (W) | 3.6 | - |
| Parallel Capability | No | - |
| Max. AC Input/Output Apparent Power (VA) | 3.6 | - |
| Electrical | ||
| Max. continuous load current | 20 A | - |
| Maximum Charge Power | 100 A | - |
| Nominal Voltage | 24 V | - |
| Max Charging Current | 100 A | - |
| Connectivity | ||
| Display | LCD Display (Display Running Mode, Loads / Input / Output etc.) | - |
| Communication | - | RS485 / CAN / Dry |
| Protection | ||
| Output Over Current Protection | 102%~110% 1min / 110%~130% 10s / 130%～150% 3s / 150% 0.2s | - |
| Ingress Protection | IP20, Indoor only | - |
| Physical | ||
| Storage Temperature | -15℃~+60℃ C | - |
| Humidity | 20%～95% (Non-condensing) | - |
| Operating Temperature | -10℃~+50℃ C | -10°C to +50° C |
| Product Weight | 6.5 kg | 20 kg |
| Package Dimensions | 285*435*100 MM | - |
| Noise | <50 | - |
| Compatibility | ||
| Brand Compatibility | Official: , | Official: , |
Overview
Brand
-
Sosen
Model
-
SSA-HL1.2~12K-P1EU
Battery Type
Lithium / Lead-acid
Lithium Lead-acid
Inverter Type
92.7%@24V d.c.
-
Output
Power Factor
1
-
Rated Power
3.6 kW
6000 W
Battery
Chemistry
Lithium / Lead-acid
-
Solar Input
Max PV Input Power
5 kW
-
Number of MPPT Trackers
1/1
1
MPPT Voltage Range
40~450 V
-
Max PV Input Current
18 A
-
Max PV Voltage (DC)
500 V
-
PV Start-up Voltage
120 V
-
Short Circuit Current (Isc)
22
-
AC Input
Rated AC Input/Output Active Power (W)
3.6
-
Parallel Capability
No
-
Max. AC Input/Output Apparent Power (VA)
3.6
-
Electrical
Max. continuous load current
20 A
-
Maximum Charge Power
100 A
-
Nominal Voltage
24 V
-
Max Charging Current
100 A
-
Connectivity
Display
LCD Display (Display Running Mode, Loads / Input / Output etc.)
-
Communication
-
RS485 / CAN / Dry
Protection
Output Over Current Protection
102%~110% 1min / 110%~130% 10s / 130%～150% 3s / 150% 0.2s
-
Ingress Protection
IP20, Indoor only
-
Physical
Storage Temperature
-15℃~+60℃ C
-
Humidity
20%～95% (Non-condensing)
-
Operating Temperature
-10℃~+50℃ C
-10°C to +50° C
Product Weight
6.5 kg
20 kg
Package Dimensions
285*435*100 MM
-
Noise
<50
-
Compatibility
Brand Compatibility
Official: ,
Official: ,
Frequently Asked Questions
Key differences from the current specs are: Rated Power (3.6 kW vs 6000 W); Product Weight (6.5 kg vs 20 kg); Number of MPPT Trackers (1/1 vs 1).
Sosen SSA-HL1.2~12K-P1EU 6kW Off-grid Hybrid Inverter currently leads on more weighted core specs (80/100 vs 20/100). For home backup, also confirm battery voltage match and your expected daily load before purchase.
Current price snapshot on SolarMarket Uganda is Sosen 3.6kW Hybrid Inverter for Home and Small Business Backup 24VDC 100A MPPT 40-450VDC 230VAC Output IP20 Indoor (SSA-HL3K6-P1EU): UGX 864,000, Sosen SSA-HL1.2~12K-P1EU 6kW Off-grid Hybrid Inverter: UGX 1,717,200. Final price depends on seller offer and availability.
Yes. You can request quotations from verified sellers using the RFQ flow: https://www.solarmarket.ug/index.php/rfq/create
