BYD Maxlite In PDU Power Distribution Unit for Battery-Max LiteIn Rack Battery, CAN/RS485, Wi-Fi, 10-Year Warranty (Maxlite In PDU)
UGX7,153,000
Sold by
Masrcorp Solar Uganda ✓
Delivery in 7 days · 10 In stock
UGX7,153,000
Want another price?Only one shop lists this right now. Send one request and other shops reply with their prices.
Ways to payAll options
Pay NowBank Transfer
Warranty
1 year · this product
Returns
7 Days · manufacturing defects
The warranty is this product's own (1 year).
7-day return window for manufacturing defects. Contact Masrcorp Solar support with your order reference to arrange an exchange or repair.
If the shop doesn't reply to a claim in 48 hours, SolarMarket steps in.
Technicians who install this
Kayigwa · @gkayigwa
Kayigwa Gonzaga
Kampala
Electrical Design
Electrical Repairs
Solar Installation
View Profile
Solaredge · @solaredge
Hybrid Solar Systems | Wholesale Supply & Expert Installation
Kampala
Solar Energy Audits
Solar Installation
Solar System Design
View Profile
Mandela · @Mandela
Electrician/solar installer and TV installer
Arua city
Solar Installation
Solar System Design
Electrical Installation
View Profile
Mwesigwa · @BALINN
An experienced electrical technician for solar energy and grid LV (240V) domesti...
ENTEBBE
Electrical Design
Data Entry
Electrical Repairs
View Profile
Ssenfuka · @SSENSWA
SOLAR INSTALLATION, Electrical Wiring, SOLAR REPAIRS, Electrical Repairs,NEW SOL...
Kampala
Appliance Repair
Solar Installation
House Wiring
View Profile
Orubo · @Orbojohnbosco19…
⚡ Trusted Electrician in Soroti | ERA Certified | Solar & Wiring Specialist
Soroti
Electrical Design
Solar Energy Audits
Solar Installation
View Profile
Sebyaayi · @Dan256rock
Quality, efficiency and timely service delivery
Luwero Town Council
Electrical Design
Landscape Design
Interior Design
View Profile
Orofino · @Brian123
YOUR GO-TO TECHNICIAN FOR ELECTRICAL AND SOLAR POWER NEEDS
Kampala
Electrical Repairs
Solar Installation
Computer Literacy
View Profile
Swipe/scroll to see more →
Key specs
Compatible System
BYD Battery-Max LiteIn
Communication
CAN/RS485/Ethernet
Warranty
1 year
| Brand | BYD | Communication | CAN/RS485 |
|---|---|---|---|
| Warranty | 10 Years | Automatic load disconnect | Handle switch (DC isolator) |
| Auxiliary output | Port for auxiliary AC power supply | Battery-connection | B+ / B- ports to the battery rack |
| SKU | SM-CAT-BYD-01062 | System Type | Battery Power Distribution Unit (PDU) |
Notice a wrong or outdated datasheet? Help us fix it.
Overview
A power distribution unit (PDU) in a battery rack system is the central interconnection point: it is where the battery string's DC output is brought together behind a main disconnect and protection device before being handed off to the inverter, and it usually carries the rack's communication backbone as well. The BYD Maxlite In PDU performs this role for the BYD Battery-Max LiteIn high voltage rack battery. On the battery side it terminates the rack's B+/B- DC connections; on the inverter side it presents P+/P- output terminals plus an 8-pin terminal block for the inverter's communication cable. It carries the CAN/RS485 port used for inverter-battery communication, plus INV ETH and ETH ports and P IN/P OUT ports for daisy-chaining communication across multiple parallel racks, along with a built-in Wi-Fi module for remote monitoring. A dedicated ground cable port, a handle-switch DC isolator, an auxiliary AC power port, and green/yellow/red alarm LEDs support safe installation, isolation, and at-a-glance status checks during commissioning and maintenance. It suits Commercial backup, Large-scale solar, Telecom backup installations built around the Battery-Max LiteIn battery. Long-term ownership is supported by a 10-Year warranty
About this item
- PURPOSE-BUILT INTERCONNECT: The dedicated power distribution unit for the BYD Battery-Max LiteIn rack battery, terminating the rack's B+/B- battery connections and presenting P+/P- outputs to the inverter.
- COMMUNICATION HUB: CAN/RS485 port for inverter-battery communication, plus INV ETH, ETH, and P IN/P OUT ports for linking multiple racks in parallel.
- REMOTE MONITORING: Built-in Wi-Fi module for status and monitoring access.
- SAFE ISOLATION: Handle-switch DC disconnect and dedicated ground cable connection point for safe commissioning and maintenance.
- STATUS AT A GLANCE: Green/Yellow/Red alarm LEDs and LED button for quick fault and status checks.
- WARRANTY: 10-Year warranty.
What's Included
- 1x BYD Maxlite In PDU. Compatible only with BYD Battery-Max LiteIn rack batteries; battery modules, inverter, and DC/communication cabling to the battery rack sold separately.
Applications
- Commercial backup systems
- Large-scale solar storage
- Telecom backup systems
- Multi-rack battery installations
- Battery-Max LiteIn system commissioning
Ask Volta about this“Will it run my fridge and pump overnight?”
Chat with Volta
What does the BYD Maxlite In PDU actually do?
It is the power distribution unit for a BYD Battery-Max LiteIn rack battery. It terminates the battery rack's DC output (B+/B-), presents P+/P- output terminals to the inverter, and carries the CAN/RS485 and Ethernet communication ports the inverter uses to read the battery's status.
Is the Maxlite In PDU compatible with other battery brands?
No. It is built specifically for the BYD Battery-Max LiteIn rack battery system and is not a generic PDU. Confirm compatibility with the specific Battery-Max LiteIn configuration before ordering.
What should installers check before commissioning a system with the Maxlite In PDU?
Confirm the ground cable connection at the dedicated grounding port, verify the handle-switch disconnect is off before wiring, connect B+/B- to the battery rack and P+/P- to the inverter, and set up the CAN/RS485 or Ethernet communication link. For multi-rack systems, use the P IN/P OUT ports to link racks in parallel.
How does the PDU support monitoring?
It has a built-in Wi-Fi module for remote monitoring, plus green, yellow, and red alarm LEDs and an LED button on the unit itself for at-a-glance status and fault checks.
What warranty applies to the BYD Maxlite In PDU?
It carries a 10-Year warranty, matching the coverage period offered on the Battery-Max LiteIn battery system it is designed for.
What should buyers compare before ordering the Maxlite In PDU in Uganda?
Compare verified seller pricing, warranty terms, authenticity, and confirm it matches the specific Battery-Max LiteIn rack configuration and inverter communication protocol (CAN/RS485 or Ethernet) being installed.
More like this
new
In stock
BYD Battery-Max LiteIn 30kWh-825kWh LiFePO4 High Voltage Rack Battery For Commercial Backup 307V-844V RS485/CAN/Modbus TCP 10-Year Warranty (Battery-Max LiteIn)
