SRNE 3.5kW Inverter Complete Solar System for Home backup power and Small business (EOT05S)

Name: SRNE 3.5kW Inverter Complete Solar System for Home backup power and Small business (EOT05S)
Brand: SRNE
SKU: SM-COM-SRN-01321
Price: 3200000.00 UGX
Availability: InStock

SRNE

0 out of 5 | 0 Ratings | Q&A

About this item

Product spotlights

Highlights: SRNE EOT05S is a complete solar system in Uganda. Key datasheet highlights include All-IN-ONE MODEL: SR-EOT03S-220; Rated Output Power: 3,500W; Max.Peak Power: 6,000VA. Use the published limits for sizing, compatibility checks, and compliant installation planning

UGX3,200,000

FREE delivery · 7 Days

10 available

Minimum order qty 1

QTY

Compare With Similar capacity Complete Solar Systems

Estimate Shipping Time 7 Days

Inhouse product

Message Seller

Brand SRNE

Products from this brand

Product Information

Technical specifications

Brand	SMA	Model	SR-EOT03S-220
Battery Type	LiFePO4	Battery Voltage	44.8~57.6 V
Rated Power	3,500W	Max Charging Current	50A
MPPT Voltage Range	60-115Vdc	Max PV Open Circuit Voltage	145Vdc
Nominal Output Voltage	230Vac	Nominal Voltage	51.2V
Surge Power	6,000VA	Product Dimensions	972555130mm
Product Weight	63 KG	Waveform	Pure Sine Wave
Efficiency	99.9%	Battery Capacity (Wh)	100Ah
Battery Energy	5.12kWh	Current Rating	100
Cycle Life	6000	Energy	2HP
Ingress Protection	IP20，Indoor Only	Input AC Voltage Range	90～280Vac
Load Motor Capacity	2HP	Max PV Input Current	40A
Max. AC Input/Output Apparent Power (VA)	3,500W	Max. Bypass Overload Current	30A
Maximum Charge Power	3,150W	Maximum input voltage	220/230Vac
Protection	Degree,IP20，Indoor Only	Rated AC Input/Output Active Power (W)	3,500W
Safety	MSDS,UN38.3,IEC61000-6:2019,NRS097	SKU	SM-COM-SRN-01321
Start Voltage	51.2

Notice a wrong or outdated datasheet? Help us fix it.

Freelancers

Verified

Verified Solar Installers for this Product

View All

Osama Mathew

Solar | water pumps | Backup systems

Kampala

Lighting Troubleshooting CAD Design

View Profile

Tamale Muhamad

Expert Solar Systems Designer & Installer – Powering Your Future!

Kampala

Solar Installation Solar Panel Cleaning Solar Water heater

View Profile

ETIENE MAATE

ElectroMechanical Engineer

Kampala

Project Management Solar Water heater Solar System Design

View Profile

Francis Ekapuloni

Professional Solar Expert

Kampala

Solar Installation Solar Energy Audits

View Profile

Okitwi Francis

Certified solar technician based in Tororo

Tororo

Solar Installation Inverter Setup Solar System Design

View Profile

Kizito Vincent

I am a technician dealing in hydro and solar power, security systems, networking...

Kampala

IT Support Electrical Repairs Battery Wiring

View Profile

Ndawula Muhamadi

Hybrid Solar Wholesale Supplier & Installer Expert

Masaka

Solar Installation Solar System Design Solar Energy Audits

View Profile

WASSWA Emmy

Solar installer

Bugiri

Electrical Repairs Solar System Design Electrical Installation

View Profile

ANITA

Solar system installation

Kampala

Electrical Repairs Appliance Repair Solar Installation

View Profile

Kibozeeyi John

Skilled Solar Installer – Expertise in Felicity, CWorth, & other quality brands

Kampala

Solar Installation Solar Panel Cleaning Solar System Design

View Profile

Swipe/scroll to see more →

Description

Specs & details

Overview

SRNE EOT05S is a complete solar system for Uganda operating conditions. It is suitable for Home backup power, Small business, Off-grid residential, Power for motor-driven. Buyers should also confirm All-IN-ONE MODEL: SR-EOT03S-220; Rated Output Power: 3,500W; Max.Peak Power: 6,000VA; Load Capacity of Motor: 2HP, verified seller pricing, warranty terms, and installer compatibility before ordering

About this item

RATED OUTPUT POWER: 3,500W continuous, with 6, peak power for starting motor loads up to 2HP.
BATTERY CAPACITY: 5.12kWh lithium iron phosphate (LFP) battery at 51.2V and 100Ah, providing 6,000 cycles at 80% depth of discharge.
MPPT SOLAR CHARGING: Single MPPT tracker with 60A maximum charging current and 99.9% tracking efficiency, accepting PV input up to 145Vdc open circuit.
AC CHARGING: Built-in AC charger delivers up to 60A (3,150W) from grid or generator input between 90-280Vac.
PURE SINE WAVE OUTPUT: 230Vac pure sine wave waveform ensures clean power for sensitive electronics and appliances.
INDOOR INSTALLATION: IP20 protection rating; designed for indoor use only. Dimensions 972x555x130mm, weight 63kg.

What's Included

SRNE SR-EOT03S-220 all-in-one unit (inverter, battery, charge controller)
User manual
Mounting brackets (if applicable, check seller offer)
AC input cable (if applicable, check seller offer)

Applications

Home backup power during grid outages
Small business lighting and equipment backup
Off-grid residential solar systems
Power for motor-driven loads such as water pumps (up to 2HP)
Daytime solar self-consumption with battery storage

Product FAQs

SRNE EOT05S is a complete solar system in Uganda. Key datasheet specs include All-IN-ONE MODEL: SR-EOT03S-220; Rated Output Power: 3,500W; Max.Peak Power: 6,000VA; Load Capacity of Motor: 2HP.

Browse live offers

Installers should verify All-IN-ONE MODEL (SR-EOT03S-220), Rated Output Power (3,500W), and Max.Peak Power (6,000VA) before commissioning SRNE EOT05S.

Browse live offers Compare models Find technicians

Compare verified seller price, warranty, authenticity, and after-sales support for SRNE EOT05S. Match all offers against the same datasheet values: All-IN-ONE MODEL: SR-EOT03S-220; Rated Output Power: 3,500W; Max.Peak Power: 6,000VA; Load Capacity of Motor: 2HP.

Browse live offers Compare models Request quotes

Installers should verify Load Capacity of Motor (2HP), ensure the mounting or system fit matches the site, and confirm any protection or operating limits listed for SRNE EOT05S.

Browse live offers Find technicians

Durability should be judged using Rated Output Voltage (230Vac) and Waveform (Pure Sine Wave), plus the warranty term and the way the product is mounted or used.

Browse live offers Request quotes

It is practical where the site needs All-IN-ONE MODEL (SR-EOT03S-220), Rated Output Power (3,500W), and Max.Peak Power (6,000VA), because those are the model's core operating limits.

Browse live offers
