Victron MPPT 75/10 MPPT Charge Controller 48V for Off-grid solar home, Small commercial solar, Rural electrification
⇄ Compare ♡ Save ↗ Share ⬇ Specs (CSV)
victron · MPPT Charge Controllers

Victron MPPT 75/10 MPPT Charge Controller 48V for Off-grid solar home, Small commercial solar, Rural electrification

UGX505,659
☆☆☆☆☆ No reviews yet ·Questions (0)
App price · Save UGX15,170Delivery in 7 days1-yr warranty
Sold by
Masrcorp Solar Uganda ✓
Delivery in 7 days · 8 In stock
UGX505,659
Want another price?Only one shop lists this right now. Send one request and other shops reply with their prices.
Similar products from other shops
30A Ajay MPPT Charge Controller 30A Ajay MPPT Charge Controller UGX363,000 AJAY SOLAR Ajay Solar 60A MPPT Solar Charge Controller Ajay Solar 60A MPPT Solar Charge Controller UGX950,400 AJAY SOLAR SRNE 60A MPPT Charge Controller for Off-Grid Solar Systems 100Vdc Open Circuit Voltage 12/24/36/48Vdc Battery (Shiner2460) SRNE 60A MPPT Charge Controller for Off-Grid Solar Systems 100Vdc Open... UGX508,200 Masrcorp Solar Uganda SRNE 20A MPPT Charge Controller for Off-Grid Solar Systems 12/24V 60VOC 260-1600W PV Input IP32 (Shiner2420) SRNE 20A MPPT Charge Controller for Off-Grid Solar Systems 12/24V 60VO... UGX21,850 Masrcorp Solar Uganda
Ways to payAll options
Pay NowBank Transfer
Warranty and returns
Warranty
1 year · this product
Returns
7 Days · unused and not installed.
Refund
Replacement only
The warranty is this product's own (1 year). Returns and refunds follow Masrcorp Solar Uganda's signed policy. If the shop doesn't reply to a claim in 48 hours, SolarMarket steps in.
Complete your systemMatched to 12 V/24 V
Solar Panels
UGX429,000
Battery
UGX1,019,520
With this product:
Technicians who install this
View All
Swipe/scroll to see more →
Key specs
Brand Victron Model MPPT 75/10
Max Charging Current 10 A Max PV Open Circuit Voltage 75 V
Nominal Voltage 12/24 V Product Dimensions 100 x 113 x 40 mm
Product Weight 0,5 kg Communication VE.Direct (see the data communication white paper on our website)
Efficiency 98 % Operating Temperature -30 to +60 °C (full rated output up to 40 °C)
Absorption Voltage 14,4 V / 28,8 V (adjustable) Automatic load disconnect Yes
Battery Type intelligent battery management Charging Algorithm multi-stage adaptive
Current Rating 10 A Float Charge Voltage 13,8 V / 27,6 V (adjustable)
Humidity 95 %, non-condensing Ingress Protection IP43 (electronic components), IP22 (connection area)
Low voltage load disconnect 11,1 V / 22,2 V / 44,4 V or 11,8 V / 23,6 V / 47,2 V or Battery Life algorithm Max. continuous load current 15 A
Max. PV short circuit current 13 A Nominal PV power, 12 V 145 W
Power terminals 6 mm² / AWG10 Protection Output short circuit / Over temperature
PV terminals 6 mm² / AWG10 Safety EN/IEC 62109-1, UL 1741, CSA C22.2
Self-consumption 12 V: 19 mA 24 V: 16 mA SKU SM-PWM-VIC-00243
Start Voltage 75 Temperature Compensation Range -16 mV / °C resp. -32 mV / °C

Notice a wrong or outdated datasheet? Help us fix it.

About this product

Overview

The Victron MPPT 75/10 MPPT Charge Controller is engineered for reliable solar charging in low voltage (LV), single phase 12V or 24V systems. With ultra-fast Maximum Power Point Tracking (MPPT) technology, it maximizes energy harvest even under fluctuating light conditions, which is common in Uganda’s climate. Integrated Bluetooth Smart allows for wireless setup, monitoring, and firmware updates via mobile devices. The controller supports intelligent battery management with programmable charging algorithms and features a load output to prevent battery over-discharge. Its robust design includes temperature compensation, short circuit protection, and recovery for fully discharged batteries, ensuring dependable operation in demanding environments. The compact form factor and IP43/IP22 protection ratings make it suitable for residential, small commercial, and rural solar installations.

About this item

  • BLUETOOTH SMART: Built-in wireless connectivity enables remote setup, monitoring, and updates via the VictronConnect app.
  • ULTRA-FAST MPPT: Advanced tracking algorithm increases solar energy harvest by up to 30% compared to PWM controllers.
  • LOAD OUTPUT: Integrated load output disconnects to prevent battery over-discharge, supporting battery longevity.
  • INTELLIGENT BATTERY MANAGEMENT: Adaptive multi-stage charging and Battery Life algorithm optimize battery health.
  • TEMPERATURE COMPENSATION: Internal sensor adjusts charging voltages based on ambient temperature for safe operation.
  • FULLY DISCHARGED BATTERY RECOVERY: Automatically initiates charging on deeply discharged batteries, including Li-ion with disconnect.

Applications

  • Off-grid solar home systems
  • Small commercial solar installations
  • Rural electrification projects
  • Solar-powered lighting
  • Telecom and remote monitoring sites
Ask Volta about this“Will it run my fridge and pump overnight?”
Chat with Volta
Frequently Asked Questions
What battery types are supported by the Victron MPPT 75/10?
The controller supports both lead-acid (flooded, AGM, GEL) and lithium batteries with programmable charging algorithms.
Can I monitor the controller remotely?
Yes, Bluetooth Smart connectivity allows wireless monitoring and configuration via the VictronConnect app on smartphones or tablets.
Is the Victron MPPT 75/10 suitable for three phase systems?
No, this model is designed for single phase, low voltage (LV) 12V or 24V systems.
What is the maximum PV input voltage and current?
The maximum PV open circuit voltage is 75V, and the maximum PV short circuit current is 13A.
Does the controller protect against battery over-discharge?
Yes, the integrated load output disconnects loads to prevent battery over-discharge based on preset voltages or the Battery Life algorithm.
Can the controller recover a fully discharged battery?
Yes, it features a recovery function that initiates charging even if the battery voltage is at zero, including lithium batteries with integrated disconnect.
Is the Victron MPPT 75/10 suitable for use in Uganda’s climate?
Yes, it operates reliably in temperatures from -30°C to +60°C and up to 95% non-condensing humidity, making it suitable for Uganda’s conditions.
