Cworth 4kW Hybrid Inverter for Home and Small Business Backup 24V DC Input 230VAC Output 120A MPPT Parallel up to 12 Units (CE-H4K)
⇄ Compare ♡ Save ↗ Share ⬇ Specs (CSV)
Cworth · Hybrid Inverters

Cworth 4kW Hybrid Inverter for Home and Small Business Backup 24V DC Input 230VAC Output 120A MPPT Parallel up to 12 Units (CE-H4K)

UGX2,102,760
☆☆☆☆☆ No reviews yet ·Questions (0)
App price · Save UGX60,000
Sold by
Cworth Energy ✓
100 In stock
UGX2,102,760
Want another price?Only one shop lists this right now. Send one request and other shops reply with their prices.
Similar products from other shops
SRNE 6kW Hybrid Inverter for Home and Small Business Backup Dual MPPT 48V 230VAC Output Parallel up to 6 Units IP65 (AEP4860S135-H) SRNE 6kW Hybrid Inverter for Home and Small Business Backup Dual MPPT... UGX2,401,960 Masrcorp Solar Uganda 3kVA 24V 48V Tbb Riio Sun Ii All In One Solar Hybrid Inverter Versatile Solar And Backup Power Solution 3kVA 24V 48V Tbb Riio Sun Ii All In One Solar Hybrid Inverter Versatil... UGX2,045,520 Masrcorp Solar Uganda Sukam 6.2kVA/5500W Hybrid Inverter for Home and Small Business Backup 48VDC 230VAC Output 120A MPPT LCD & App Monitoring (FX6200-48H) Sukam 6.2kVA/5500W Hybrid Inverter for Home and Small Business Backup... UGX2,030,400 Auto Solutions plus ltd 2kVA 24V Tbb Riio Sun Ii All In One Solar Hybrid Inverter Versatile Solar And Backup Power Solution 2kVA 24V Tbb Riio Sun Ii All In One Solar Hybrid Inverter Versatile So... UGX1,909,440 Masrcorp Solar Uganda
Ways to payAll options
Pay NowBank Transfer
Complete your systemMatched to 24 V
Solar Panels
UGX429,000
Battery
UGX1,784,160
Cables, mounting and protection
UGX47,817
With this product:
Technicians who install this
View All
Swipe/scroll to see more →
Key specs
Brand Cworth Model CE-H4K
Rated Power 4000 W Max PV Input Power 4000W
Max Charging Current 10A-Max. Grid Charge Curent (Adjustable unit is 1A) MPPT Voltage Range 85V-450V
Max PV Open Circuit Voltage 500 V Nominal Output Voltage 230Vact5%
Nominal Output Frequency (Hz),50+0.3Hz/60Hz+0.3Hz (Adjustable) Nominal Voltage 85 V
Product Dimensions 347x445x120mm Product Weight 9.2 KG
Waveform Pure sine wave Efficiency 93%
Operating Temperature -10°C~55°C AC Output Rated Current 18.2A
Battery Type Flooded 29.2V/58.4V 27V/54V Chemistry Lithium
Current Rating 18.2 A High DC Input Alarm & Fault 31V+0.2V
High Line Voltage Disconnect 280Vact+3V Input AC Voltage Range 85 V
Low DC Input Shut-down Recovery 29V+40.2V Low voltage load disconnect 170Vac+3V (For Computers)
Max PV Input Current 15A Max. AC Input/Output Apparent Power (VA) AOOOW
Max. PV short circuit current 170Vac+3V (For Computers) Max. Shorted Current 18.2A/4000W
Output Short Circuit Protection Yes Overcharge Protection Yes
Parallel Capability Yes,up to 12 units Pass Through Without Battery Yes
Rated AC Input/Output Active Power (W) 4000W Self Discharge Adjustable, up to 30V/60V
SKU SM-CAT-GEN-00929 Storage Temperature -15°C~60°C
Transfer Time 10ms typical (UPS);20ms typical (Appliances)

Notice a wrong or outdated datasheet? Help us fix it.

About this product

Overview

Cworth CE-H4K is a 4kW 24V hybrid inverter for Uganda power conditions. It supports the published PV input limit and is suitable for Home backup power, Small business power, Off-grid solar where dependable backup and solar charging are required. Buyers should also confirm the datasheet limits, warranty coverage, seller authenticity, and installer compatibility before ordering

About this item

  • RATED OUTPUT POWER: 4000W continuous output at 230VAC with pure sine wave waveform, suitable for sensitive electronics and appliances.
  • SOLAR CHARGING: Integrated 120A MPPT solar charger with a PV voltage range of 85V-450V and maximum input power of 4000W, enabling efficient solar harvesting.
  • BATTERY COMPATIBILITY: Supports AGM, Flooded, and Lithium battery types with adjustable charge voltage up to 30V/60V and a maximum charging current of 100A from the grid.
  • PARALLEL OPERATION: Expandable to 12 units in parallel for increased power capacity, with a transfer time of 10ms typical in UPS mode.
  • PASS-THROUGH FUNCTION: Operates without a battery connected, allowing direct pass-through of utility or generator power to loads.
  • PROTECTION FEATURES: Includes overcharge protection, output short circuit protection, and high DC input alarm and fault at 31V+0.2V.

What's Included

  • 1x Cworth CE-H4K Hybrid Inverter
  • User manual
  • Warranty card (terms vary by seller)

Applications

  • Home backup power during grid outages
  • Small business power backup for computers and lighting
  • Off-grid solar systems with 24V battery banks
  • UPS replacement for sensitive electronic equipment
  • Scalable multi-unit installations for larger loads
Ask Volta about this“Will it run my fridge and pump overnight?”
Chat with Volta
Frequently Asked Questions
What are the key specs of Cworth CE-H4K in Uganda?
Cworth CE-H4K is a 4kW hybrid inverter in Uganda. Key specs include battery voltage range 24V, max PV input voltage SOOV, rated AC output 4kW.
What PV voltage limits should technicians use for Cworth CE-H4K?
For Cworth CE-H4K, use MPPT/operating voltage range 85V-450V, max PV input voltage SOOV, and max PV input power the listed PV input power when designing strings.
How much solar PV can be connected to Cworth CE-H4K?
Cworth CE-H4K allows up to the listed limit PV input power. Use MPPT range 85V-450V, max PV input voltage SOOV for string sizing checks.
What battery and charge current settings apply to Cworth CE-H4K?
Cworth CE-H4K is built for 24V battery systems. The battery voltage range is 24V, with maximum charging current 100A.
What AC output should buyers and installers expect from Cworth CE-H4K?
Cworth CE-H4K has a rated AC output of 4kW. It operates with grid frequency 50/60Hz (Auto detection) and AC voltage range 230Vact5%. If needed, use the listed input range for compatibility checks.
What should buyers compare before ordering Cworth CE-H4K in Uganda?
Compare verified seller pricing, warranty terms, authenticity, and installer support for Cworth CE-H4K. Also match battery voltage range, MPPT layout, max PV input voltage, communication, monitoring, AC output, and warranty against the datasheet.
