Growatt 5kVA 5000W Hybrid Inverter for Home and Small Business Backup 48VDC 230VAC Output MPPT 120-430VDC Expandable to 6 Units IP20 (SPF-5000-ES)
⇄ Compare ♡ Save ↗ Share ⬇ Specs (CSV)
Growatt · Hybrid Inverters

Growatt 5kVA 5000W Hybrid Inverter for Home and Small Business Backup 48VDC 230VAC Output MPPT 120-430VDC Expandable to 6 Units IP20 (SPF-5000-ES)

UGX5,064,929
☆☆☆☆☆ No reviews yet ·Questions (0)
App price · Save UGX101,299Delivery in 7 days1-yr warranty
Sold by
Masrcorp Solar Uganda ✓
Delivery in 7 days · In stock
UGX5,064,929
Want another price?Only one shop lists this right now. Send one request and other shops reply with their prices.
Similar products from other shops
Entelechy 60kW High Voltage Hybrid Inverter for Commercial and Large-scale grid-tied 850V Battery MPPT 1000V (BST-HPI-60KW-H3) Entelechy 60kW High Voltage Hybrid Inverter for Commercial and Large-s... UGX5,633,564 Entelechy Solar Solutions SRNE 6kW Hybrid Inverter for Home and Small Business Backup 48V 230VAC Dual MPPT 120-450VDC Expandable to 6 Units IP65 5-Year Warranty (HESP4860S100-H) SRNE 6kW Hybrid Inverter for Home and Small Business Backup 48V 230VAC... UGX5,669,092 BLISON ENERGY Cosuper 5kW 48V Solar Hybrid Inverter Pure Sine Wave MPPT 60A Parallel 3 Phase Support Spe5000 Cosuper 5kW 48V Solar Hybrid Inverter Pure Sine Wave MPPT 60A Parallel... UGX4,081,000 Baseline Africa Uganda Sukam 11kW Hybrid Inverter for Home and Small Business Backup 48V 150A MPPT 90-450VDC Dual MPPT Parallel up to 6 Units RS232 USB WiFi (FX1100-48H) Sukam 11kW Hybrid Inverter for Home and Small Business Backup 48V 150A... UGX4,028,000 Auto Solutions plus ltd
Ways to payAll options
Pay NowBank Transfer
Warranty and returns
Warranty
1 year · this product
Returns
7 Days · unused and not installed.
Refund
Replacement only
The warranty is this product's own (1 year). Returns and refunds follow Masrcorp Solar Uganda's signed policy. If the shop doesn't reply to a claim in 48 hours, SolarMarket steps in.
Complete your systemMatched to 48 V
Solar Panels
UGX429,000
Battery
UGX8,257,400
Cables, mounting and protection
UGX41,176
With this product:
Technicians who install this
View All
Swipe/scroll to see more →
Key specs
Brand Growatt Rated Power 5000VA/ 5000W
Max PV Input Power 6000 W Max Charging Current 80A
MPPT Voltage Range 120 V Nominal Voltage 48 V
Surge Power 10000VA Product Dimensions 330/485/135mm
Product Weight 12 KG Waveform Pure sine wave
Efficiency 93% Operating Temperature 0°C - 55°C
Battery Type Lithium/Lead-acid Chemistry Lead-acid
Current Rating 100 A Humidity 5% to 95% Relative Humidity(Non-condensing)
Ingress Protection IP20 Input AC Voltage Range 230 VAC
Input Voltage Range 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) Max AC Input Voltage 230 VAC
Max PV Short Circuit Current (per tracker) 22A Max. AC Input/Output Apparent Power (VA) 5000VA/ 5000W
Max. PV short circuit current Datasheet SPF 5000 ES Maximum Charge Power 6000W
Parallel Capability Yes, 6 units maximum Permissible Altitude <2000m
Protection degree,IP20 Rated AC Input/Output Active Power (W) 5000VA/ 5000W
Short-circuit Current (Isc) Datasheet SPF 5000 ES SKU SM-HYB-GRO-01198
Start Voltage 48 Storage Temperature -15°C - 60°C
Transfer Time 10ms typical, 20ms Max

Notice a wrong or outdated datasheet? Help us fix it.

About this product

Overview

Growatt SPF-5000-ES is a 5kW 48V hybrid inverter for Uganda power conditions. It supports up to 6kW PV input and is suitable for Home solar backup, Small business power, Off-grid solar where dependable backup and solar charging are required. Buyers should also confirm the datasheet limits, warranty coverage, seller authenticity, and installer compatibility before ordering

About this item

  • RATED POWER: 5kVA/5000W continuous output, with 10kVA surge capability for starting motor loads.
  • BATTERY COMPATIBILITY: Works with 48VDC lithium or lead-acid battery banks; selectable charging profile via LCD settings.
  • MPPT SOLAR CHARGING: Dual MPPT trackers accept PV array voltage from 120VDC to 430VDC, maximum 6000W total PV input.
  • PARALLEL OPERATION: Expandable to 6 units in parallel for up to 30kVA total system capacity.
  • TRANSFER TIME: 10ms typical (20ms max) automatic switch between grid and battery power, safe for sensitive electronics.
  • PROGRAMMABLE SCHEDULING: Built-in timer allows flexible setting of charging and discharging periods to optimise battery use.

What's Included

  • 1x Growatt SPF-5000-ES Hybrid Inverter
  • 1x User Manual
  • 1x Warranty Card

Applications

  • Home solar backup during load shedding
  • Small business power backup for computers and lighting
  • Off-grid solar system with battery storage
  • Grid-tied solar system with battery backup
  • Remote telecom or security system power
Ask Volta about this“Will it run my fridge and pump overnight?”
Chat with Volta
Frequently Asked Questions
What are the key specs of Growatt SPF-5000-ES in Uganda?
Growatt SPF-5000-ES is a 5kW hybrid inverter in Uganda. Key specs include battery voltage range 48V, max PV input power 6kW, rated AC output 5kW.
What PV voltage limits should technicians use for Growatt SPF-5000-ES?
For Growatt SPF-5000-ES, use MPPT/operating voltage range 120VDC ~ 430VDC, max PV input voltage the listed max PV voltage, and max PV input power 6kW when designing strings.
How much solar PV can be connected to Growatt SPF-5000-ES?
Growatt SPF-5000-ES allows up to 6kW PV input power. Use MPPT range 120VDC ~ 430VDC for string sizing checks.
What battery and charge current settings apply to Growatt SPF-5000-ES?
Growatt SPF-5000-ES is built for 48V battery systems. The battery voltage range is 48V, with maximum charging current 100A.
What AC output should buyers and installers expect from Growatt SPF-5000-ES?
Growatt SPF-5000-ES has a rated AC output of 5kW. It operates with grid frequency 50Hz/60Hz (Auto sensing) and AC voltage range 230 VAC. If needed, use 230 VAC for compatibility checks.
What should buyers compare before ordering Growatt SPF-5000-ES in Uganda?
Compare verified seller pricing, warranty terms, authenticity, and installer support for Growatt SPF-5000-ES. Also match battery voltage range, MPPT layout, max PV input voltage, communication, monitoring, AC output, and warranty against the datasheet.
