DEYE 10kW Single Phase Hybrid Inverter for Home and Small Business Backup 230VAC Output 48V Battery 500V PV Input Dual MPPT 150-425VDC 97.6% Efficiency IP65 (SUN-10K-SG05LP1-EU-AM2-P)

Name: DEYE 10kW Single Phase Hybrid Inverter for Home and Small Business Backup 230VAC Output 48V Battery 500V PV Input Dual MPPT 150-425VDC 97.6% Efficiency IP65 (SUN-10K-SG05LP1-EU-AM2-P)
Brand: Deye
SKU: SM-HYB-DEY-00697
Price: 8475000.00 UGX
Availability: InStock

Deye

0 out of 5 | 0 Ratings | Q&A

About this item

Product spotlights

Highlights: DEYE SUN-10K-SG05LP1-EU-AM2-P is a 10kW 500V hybrid inverter in Uganda. It supports up to 16kW PV input and is built for Home solar backup in, Small business power, Off-grid where battery-backed continuity and stable AC output matter

UGX8,475,000

FREE delivery · 7 Days

10 available

Minimum order qty 1

QTY

Compare With Similar capacity Hybrid Inverters

Estimate Shipping Time 7 Days

Inhouse product

Message Seller

Brand Deye

Products from this brand

Product Information

Technical specifications

Brand	SMA	Model	IP65
Rated Power	10000	Max PV Input Power	20000 W
Max Charging Current	210 A	MPPT Voltage Range	150-425
Nominal Voltage	40-60 V	Surge Power	d)(W),"2 times of rated power, 10s"
Product Dimensions	330×580×232 (Excluding Connectors and Brackets)	Product Weight	24.9 KG
Communication	RS485/RS232/CAN	Efficiency	97.6%
Operating Temperature	Range (℃),"-40 to +60℃, >45℃ Derating"	Warranty	5 Years/10 Years
AC Output Rated Current	45.5/43.5	Battery Type	Lead-acid or Lithium-ion
Chemistry	Lead-acid	Current Rating	210
DC Injection Current	<0.5% In	Input AC Voltage Range	220/230 0.85Un-1.1Un
Inverter Type	Non-Isolated	Junction Box (IP Rating)	IP 65
Max AC Input Voltage	500 V	Max PV Input Current	32+32
Max. AC Input/Output Apparent Power (VA)	11000	Max. Continuous AC Passthrough	50 A
Max. PV short circuit current	210	Monitor Module	GPRS/WIFI/Bluetooth/4G/LAN(optional)
Number of Battery Modules	1	Over Voltage Category	OVC II(DC), OVC III(AC)
Permissible Altitude	0-100%	Power Factor	0.8 leading to 0.8 lagging
Protection	TYPE II(DC), TYPE II(AC)	PV Start-up Voltage	125 V
Rated AC Input/Output Active Power (W)	10000 W	SKU	SM-HYB-DEY-00697
Start Voltage	up Voltage (V),125

Notice a wrong or outdated datasheet? Help us fix it.

Freelancers

Verified

Verified Solar Installers for this Product

View All

Okitwi Francis

Certified solar technician based in Tororo

Tororo

Solar Installation Inverter Setup Solar System Design

View Profile

WASSWA Emmy

Solar installer

Bugiri

Electrical Repairs Solar System Design Electrical Installation

View Profile

Osama Mathew

Solar | water pumps | Backup systems

Kampala

Lighting Troubleshooting CAD Design

View Profile

Ndawula Muhamadi

Hybrid Solar Wholesale Supplier & Installer Expert

Masaka

Solar Installation Solar System Design Solar Energy Audits

View Profile

Kizito Vincent

I am a technician dealing in hydro and solar power, security systems, networking...

Kampala

IT Support Electrical Repairs Battery Wiring

View Profile

ANITA

Solar system installation

Kampala

Electrical Repairs Appliance Repair Solar Installation

View Profile

Tamale Muhamad

Expert Solar Systems Designer & Installer – Powering Your Future!

Kampala

Solar Installation Solar Panel Cleaning Solar Water heater

View Profile

ETIENE MAATE

ElectroMechanical Engineer

Kampala

Project Management Solar Water heater Solar System Design

View Profile

Kibozeeyi John

Skilled Solar Installer – Expertise in Felicity, CWorth, & other quality brands

Kampala

Solar Installation Solar Panel Cleaning Solar System Design

View Profile

Francis Ekapuloni

Professional Solar Expert

Kampala

Solar Installation Solar Energy Audits

View Profile

Swipe/scroll to see more →

Description

Specs & details

Overview

DEYE SUN-10K-SG05LP1-EU-AM2-P is a 10kW 500V hybrid inverter for Uganda power conditions. It supports up to 16kW PV input and is suitable for Home solar backup in, Small business power, Off-grid where dependable backup and solar charging are required. Buyers should also confirm the datasheet limits, warranty coverage, seller authenticity, and installer compatibility before ordering

About this item

RATED POWER OUTPUT: 10,000W continuous AC output with 11, apparent power, supporting typical home and small business loads in Uganda.
DUAL MPPT TRACKERS: Two independent MPPT channels with a voltage range of 150-425V and 32A maximum current per channel, optimizing energy harvest from partially shaded or differently oriented solar arrays.
BATTERY COMPATIBILITY: Works with 48V lead-acid or lithium-ion battery banks, with a voltage range of 40-60V and a maximum charge/discharge current of 210A.
HIGH EFFICIENCY: Maximum conversion efficiency of 97.6% and Euro efficiency of 96.5%, reducing energy losses during solar-to-battery and battery-to-load conversion.
IP65 ENCLOSURE: Weather-resistant housing rated IP65, allowing installation outdoors or in dusty environments common in Ugandan installations.
PEAK POWER CAPABILITY: Delivers up to 2 times rated power (20,000W) for 10 seconds, handling startup surges from motors, pumps, and compressors.

What's Included

DEYE SUN-10K-SG05LP1-EU-AM2-P Hybrid Inverter Unit
Mounting brackets
User manual
Communication cable (RS485)
Warranty card

Applications

Home solar backup systems in Uganda
Small business power backup for shops and offices
Off-grid and grid-tied hybrid solar installations
Battery-based solar systems for areas with unreliable grid power
Commercial applications requiring single phase 230VAC backup

Product FAQs

DEYE SUN-10K-SG05LP1-EU-AM2-P is a 10kW hybrid inverter in Uganda. Key specs include battery voltage range 48V, max PV input voltage 500, max PV input power 16kW, rated AC output 10kW, communication RS485/CAN, monitoring WiFi Monitoring, warranty 5 Years/10 Years.

Browse live offers

For DEYE SUN-10K-SG05LP1-EU-AM2-P, use MPPT/operating voltage range 150-425, max PV input voltage 500, and max PV input power 16kW when designing strings.

Browse live offers Find technicians

DEYE SUN-10K-SG05LP1-EU-AM2-P allows up to 16kW PV input power. Use MPPT range 150-425, max PV input voltage 500 for string sizing checks.

Browse live offers

DEYE SUN-10K-SG05LP1-EU-AM2-P is built for 48V battery systems. The battery voltage range is 48V, with maximum charging current 210 and maximum discharging current 210.

Browse live offers

DEYE SUN-10K-SG05LP1-EU-AM2-P has a rated AC output of 10kW. It operates with grid frequency the listed grid frequency and AC voltage range 220/230 0.85Un-1.1Un. If needed, use 10000 for compatibility checks.

Browse live offers Request quotes Find technicians

Compare verified seller pricing, warranty terms, authenticity, and installer support for DEYE SUN-10K-SG05LP1-EU-AM2-P. Also match battery voltage range, MPPT layout, max PV input voltage, communication, monitoring, AC output, and warranty against the datasheet.
