Felicity 100Ah 12V GEL Battery for Solar VS Felicity 200Ah 12V GEL Solar Battery for
VS
A/B
Specifications Comparison
Spec keys are preserved from both products. We never remove a key just because the other product has no value yet.
| Feature | Felicity 100Ah 12V GEL Battery for Solar | Felicity 200Ah 12V GEL Solar Battery for |
|---|---|---|
| Overview | ||
| Brand | Felicity | Felicity |
| Model | G12V100AH | G12V200AH |
| Power | ||
| Rated Power | - | 1447 W |
| Electrical | ||
| Nominal Voltage | 12 V | 12 V |
| Voltage Per Unit | 12V | 12V |
| Equalization / Cycle Service Voltage | 14.4 – 14.6V DC @25°C | 14.4 to 14.6V DC/unit Average at 25°C |
| Energy | 100Ah kWh | 200Ah kWh |
| Max Charging Current | 30 A | 60 A |
| Capacity | 100 Ah | 200 Ah |
| Chemistry | Gel | Gel (Sealed Lead-Acid / VRLA) |
| Performance | ||
| Constant Current Discharge (1HR, 9.60V) | - | 124.8 A |
| Cycle Life | 400 Cycles | 750 Cycles |
| Float Charge Voltage | 13.6 – 13.8V DC @25°C V | 13.6 to 13.8V DC/unit Average at 25°C V |
| Self Discharge | Less than 3% per month after 25°C (charge before use if stored >6 M | - |
| Connectivity | ||
| Communication | CAN2.0/RS485 | CAN2.0/RS485 |
| Physical | ||
| Operating Temperature Range Discharge | -20°C ~ 60°C | Charge: 0°C ~ 50°C | -20°C ~ 60°C |
| Operating Temperature | 25°C ± 5 °C | Range: 25°C ± 5° C |
| Storage Temperature | - | -20°C ~ 60° C |
| Warranty | 1 Years | 1 year Years |
| Module Dimensions | - | 522x240x219 mm |
| Product Dimensions | 330×171×218 mm | 522x240x240 mm |
| Product Weight | 31.5 kg | 61.5 kg |
| Compatibility | ||
| Brand Compatibility | Official: , | Official: , |
| Other Specs | ||
| Nominal Capacity (Ah) | - | 262.6 |
| Internal Resistance | Approx. 5.0 mΩ M | Approx. 4.0mΩ |
| Cells Per Unit | 6 | - |
Overview
Brand
Felicity
Felicity
Model
G12V100AH
G12V200AH
Power
Rated Power
-
1447 W
Electrical
Nominal Voltage
12 V
12 V
Voltage Per Unit
12V
12V
Equalization / Cycle Service Voltage
14.4 – 14.6V DC @25°C
14.4 to 14.6V DC/unit Average at 25°C
Energy
100Ah kWh
200Ah kWh
Max Charging Current
30 A
60 A
Capacity
100 Ah
200 Ah
Chemistry
Gel
Gel (Sealed Lead-Acid / VRLA)
Performance
Constant Current Discharge (1HR, 9.60V)
-
124.8 A
Cycle Life
400 Cycles
750 Cycles
Float Charge Voltage
13.6 – 13.8V DC @25°C V
13.6 to 13.8V DC/unit Average at 25°C V
Self Discharge
Less than 3% per month after 25°C (charge before use if stored >6 M
-
Connectivity
Communication
CAN2.0/RS485
CAN2.0/RS485
Physical
Operating Temperature Range Discharge
-20°C ~ 60°C | Charge: 0°C ~ 50°C
-20°C ~ 60°C
Operating Temperature
25°C ± 5 °C
Range: 25°C ± 5° C
Storage Temperature
-
-20°C ~ 60° C
Warranty
1 Years
1 year Years
Module Dimensions
-
522x240x219 mm
Product Dimensions
330×171×218 mm
522x240x240 mm
Product Weight
31.5 kg
61.5 kg
Compatibility
Brand Compatibility
Official: ,
Official: ,
Other Specs
Nominal Capacity (Ah)
-
262.6
Internal Resistance
Approx. 5.0 mΩ M
Approx. 4.0mΩ
Cells Per Unit
6
-
Frequently Asked Questions
Key differences from the current specs are: Capacity (100AH @10Hr-Rate Ah vs 200Ah); Nominal Voltage (12 V vs 80 V); Max Charging Current (30 A vs 60 A).
Felicity Gel 200AH 12V G12V200AH Solar Battery for Off-grid solar power, Residential backup, Telecommunications currently leads on more weighted core specs (82/100 vs 18/100). For home backup, also confirm battery voltage match and your expected daily load before purchase.
Current price snapshot on SolarMarket Uganda is Felicity G12V100AH 1.2kWh 12V 100Ah Gel Deep Cycle Battery for Home Backup, Solar Storage and Remote Power | 1-Year Warranty: UGX 508,200, Felicity Gel 200AH 12V G12V200AH Solar Battery for Off-grid solar power, Residential backup, Telecommunications: UGX 968,000. Final p
Yes. You can request quotations from verified sellers using the RFQ flow: https://www.solarmarket.ug/rfq/create
