Pedrollo 6Sr Submersible Borehole Pump High Flow 6 Stainless Steel Pump For Deep Wells Irrigation Sb Innovations Uganda
About this item
Highlights: The Pedrollo 6SR is a 6-inch submersible borehole pump designed for deep wells and irrigation, offering high-flow performance to efficiently move large volumes of water. Its stainless steel construction ensures durability and corrosion resistance in demanding environments. This pump is compatible with deep well applications and features a high-flow design suitable for irrigation systems.
Product Information
Technical specifications| Brand | Pedrollo | SKU | SM-SUB-PED-00444 |
|---|
Notice a wrong or outdated datasheet? Help us fix it.
Freelancers
VerifiedVerified Solar Installers for this Product
View All
Description
Specs & detailsThe Pedrollo 6SR Series is a high-performance line of 6-inch submersible borehole pumps engineered for demanding water applications in Uganda’s domestic, agricultural, and commercial sectors. Designed with abrasion-resistant materials, the 6SR pumps deliver consistent water output even in wells with sand content up to 100 g/m³6SR_EN-datasheet_50Hz.
With flow rates up to 1000 L/min (60 m³/h) and heads reaching 390 meters, these pumps are perfect for deep wells, irrigation farms, commercial water transfer, fire-fighting systems, and pressure boosting.
All models are powered by three-phase 400V motors, available in oil-filled (6PD) or water-filled (6PSR) versions, and come pre-assembled with a 4-meter cable.
⚙️ Key Features & Benefits
✅ Wide Range of Power & Flow
-
Available from 4kW to 30kW
-
Handles flows from 200 to 1000 L/min
-
Maximum head: up to 390m6SR_EN-datasheet_50Hz
✅ Sand-Tolerant Hydraulic Design
Floating impellers and sand-resistant bearings allow safe operation in sandy boreholes (up to 100 g/m³).
✅ Heavy-Duty Stainless Steel Construction
Pump body, shaft, filter, sleeve, and check valve all made from AISI 304/316 stainless steel for corrosion resistance and long life6SR_EN-datasheet_50Hz.
✅ Flexible Mounting Options
Supports vertical installation up to 200m depth, and limited horizontal use for tanks or open reservoirs (up to 11 kW / 12 stages)6SR_EN-datasheet_50Hz.
✅ Energy Efficient – MEI ≥ 0.40
Optimized hydraulic design reduces energy consumption and runtime for large pumping systems6SR_EN-datasheet_50Hz.
✅ Cooling Jacket Ready (Optional)
For river/lake/reservoir use, supports optional cooling jackets to maintain safe motor temperature.
✅ Ready-to-Install with 4m Cable
Minimizes installer setup time.
? Applications – Ideal For:
-
? Deep Borehole Water Supply for Homes & Estates
-
? Large-Scale Irrigation for Commercial Farms
-
? Overhead Tank Filling from 60m–300m Depths
-
? Fire-Fighting & Booster Systems in Buildings
-
? Livestock & Poultry Watering Systems
-
? Industrial & Rural Water Transfer Solutions
? Top Performing Models
| Model | Power (kW/HP) | Max Flow (L/min) | Max Head (m) |
|---|---|---|---|
| 6SR 12/28 | 15 kW / 20 HP | 330 L/min | 390 m |
| 6SR 18/22 | 18.5 kW / 25 HP | 450 L/min | 298 m |
| 6SR 27/27 | 30 kW / 40 HP | 600 L/min | 367 m |
| 6SR 36/22 | 22 kW / 30 HP | 800 L/min | 274 m |
| 6SR 44/25 | 30 kW / 40 HP | 1000 L/min | 310 m |
? Sold by SB Innovations Uganda on Solar Market Uganda
✅ Authentic Pedrollo Pumps
✅ Bulk pricing for contractors & installers
✅ Technical support & delivery across Uganda
