Victron MPPT 75/10 MPPT Charge Controller 48V for Off-grid solar home, Small commercial solar, Rural electrification

Name: Victron MPPT 75/10 48V MPPT Charge Controller | Best Price Uganda
Brand: victron
SKU: SM-PWM-VIC-00243
Price: 437800.00 UGX
Availability: InStock

victron

0 out of 5 | 0 Ratings | Q&A

About this item

Product spotlights

Highlights: The Victron MPPT 75/10 is a 48V charge controller for off-grid solar systems, optimizing energy harvest from solar panels to batteries. It ensures efficient charging and extends battery life. Compatible with 48V battery banks, it handles up to 75V input and 10A output, suitable for various panel configurations.

UGX481,580

Variation

8 available

Minimum order qty 1

QTY

Order on WhatsApp

Selected Product Summery

Victron MPPT 75/10 MPPT Charge Controller 48V for Off-grid solar home, Small commercial solar, Rural electrification -

Compare With Similar capacity MPPT Charge Controllers

Sold by Masrcorp Solar Uganda

Message Seller

Brand victron

Products from this brand

Product Information

Technical specifications

Brand	Victron	Model	MPPT 75/10
Max Charging Current	10	Nominal Voltage	48
Product Dimensions	100 x 113 x 40mm	Product Weight	0,5kg
Communication	VE.Direct (see the data communication white paper on our website)	Efficiency	98
Operating Temperature	-30 to +60 °C (full rated output up to 40 °C)	Absorption Voltage	14,4V / 28,8V (adjustable)
Automatic load disconnect	Yes	Charging Algorithm	multi-stage adaptive
Float Charge Voltage	13,8V / 27,6V (adjustable)	Humidity	95 %, non-condensing
Low voltage load disconnect	11,1V / 22,2V / 44,4V or 11,8V / 23,6V / 47,2V or Battery Life algorithm	Max PV Short Circuit Current (per tracker)	13
Max PV Voltage (DC)	75	Max. continuous load current	15A
Protection	Output short circuit / Over temperature	Protection Category (IP)	IP43 (electronic components), IP22 (connection area)
PV terminals	6mm² / AWG10	Safety	EN/IEC 62109-1, UL 1741, CSA C22.2
Self-consumption	12V: 19 mA 24V: 16	SKU	SM-PWM-VIC-00243
Temperature Compensation Range	-16 mV / °C resp. -32 mV / °C

Notice a wrong or outdated datasheet? Help us fix it.

Freelancers

Verified

Verified Solar Installers for this Product

View All

Kizito Vincent

I am a technician dealing in hydro and solar power, security systems, networking...

Kampala

IT Support Electrical Repairs Battery Wiring

View Profile

ETIENE MAATE

ElectroMechanical Engineer

Kampala

Project Management Solar Water heater Solar System Design

View Profile

Kibozeeyi John

Skilled Solar Installer – Expertise in Felicity, CWorth, & other quality brands

Kampala

Solar Installation Solar Panel Cleaning Solar System Design

View Profile

WASSWA Emmy

Solar installer

Bugiri

Electrical Repairs Solar System Design Electrical Installation

View Profile

Tamale Muhamad

Expert Solar Systems Designer & Installer – Powering Your Future!

Kampala

Solar Installation Solar Panel Cleaning Solar Water heater

View Profile

ANITA

Solar system installation

Kampala

Electrical Repairs Appliance Repair Solar Installation

View Profile

Ndawula Muhamadi

Hybrid Solar Wholesale Supplier & Installer Expert

Masaka

Solar Installation Solar System Design Solar Energy Audits

View Profile

Francis Ekapuloni

Professional Solar Expert

Kampala

Solar Installation Solar Energy Audits

View Profile

Osama Mathew

Solar | water pumps | Backup systems

Kampala

Lighting Troubleshooting CAD Design

View Profile

MWESIGWA JOEL BALINNYA

An experienced electrical technician for solar energy and grid LV (240V) domesti...

ENTEBBE

Electrical Design Data Entry Electrical Repairs

View Profile

Swipe/scroll to see more →

Description

Specs & details

Overview

The Victron MPPT 75/10 MPPT Charge Controller is engineered for reliable solar charging in low voltage (LV), single phase 12V or 24V systems. With ultra-fast Maximum Power Point Tracking (MPPT) technology, it maximizes energy harvest even under fluctuating light conditions, which is common in Uganda’s climate. Integrated Bluetooth Smart allows for wireless setup, monitoring, and firmware updates via mobile devices. The controller supports intelligent battery management with programmable charging algorithms and features a load output to prevent battery over-discharge. Its robust design includes temperature compensation, short circuit protection, and recovery for fully discharged batteries, ensuring dependable operation in demanding environments. The compact form factor and IP43/IP22 protection ratings make it suitable for residential, small commercial, and rural solar installations.

About this item

BLUETOOTH SMART: Built-in wireless connectivity enables remote setup, monitoring, and updates via the VictronConnect app.
ULTRA-FAST MPPT: Advanced tracking algorithm increases solar energy harvest by up to 30% compared to PWM controllers.
LOAD OUTPUT: Integrated load output disconnects to prevent battery over-discharge, supporting battery longevity.
INTELLIGENT BATTERY MANAGEMENT: Adaptive multi-stage charging and Battery Life algorithm optimize battery health.
TEMPERATURE COMPENSATION: Internal sensor adjusts charging voltages based on ambient temperature for safe operation.
FULLY DISCHARGED BATTERY RECOVERY: Automatically initiates charging on deeply discharged batteries, including Li-ion with disconnect.

Product FAQs

Use the rated output value in the technical specs to size loads correctly for Victron MPPT 75/10 MPPT Charge Controller 48V for Off-grid solar home, Small commercial solar, Rural electrification.

Browse live offers

Victron MPPT 75/10 MPPT Charge Controller 48V for Off-grid solar home, Small commercial solar, Rural electrification is configured for 10A systems. Match battery bank voltage to this value for safe operation.

Browse live offers Compare models Use solar calculator

MPPT/charge limit is 10A. Design array and charging settings within these limits.

Browse live offers

Victron MPPT 75/10 MPPT Charge Controller 48V for Off-grid solar home, Small commercial solar, Rural electrification is 10A. Match this phase type to site distribution before installation.

Browse live offers

Compare rated output, system voltage (10A), charge limit (10A) side by side before selecting the best offer.

Browse live offers Compare models
