Victron MPPT 75/10 MPPT Charge Controller 48V for Off-grid solar home, Small commercial solar, Rural electrification

Name: Victron MPPT 75/10 MPPT Charge Controller 48V for Off-grid solar home, Small commercial solar, Rural electrification
Brand: victron
SKU: SM-PWM-VIC-00243
Price: 459690.00 UGX
Availability: InStock

victron

0 out of 5 | 0 Ratings | Q&A

About this item

Product spotlights

Highlights: The Victron MPPT 75/10 is a low voltage (LV), single phase MPPT charge controller designed for 12V or 24V solar systems. It features Bluetooth Smart connectivity for easy monitoring and configuration, making it suitable for off-grid and backup applications in Uganda.

UGX459,690

7 Days

Variation

8 available

Minimum order qty 1

QTY

Order on WhatsApp

Selected Product Summery

Victron MPPT 75/10 MPPT Charge Controller 48V for Off-grid solar home, Small commercial solar, Rural electrification -

Compare With Similar capacity MPPT Charge Controllers

Estimate Shipping Time 7 Days

Sold by Masrcorp Solar Uganda

Message Seller

Brand victron

Products from this brand

Product Information

Technical specifications

Brand	Victron	Model	MPPT 75/10
Max Charging Current	10 A	Max PV Open Circuit Voltage	75 V
Nominal Voltage	12/24 V	Product Dimensions	100 x 113 x 40 mm
Product Weight	0,5 kg	Communication	VE.Direct (see the data communication white paper on our website)
Efficiency	98 %	Operating Temperature	-30 to +60 °C (full rated output up to 40 °C)
Absorption Voltage	14,4 V / 28,8 V (adjustable)	Automatic load disconnect	Yes
Battery Type	intelligent battery management	Charge voltage 'equalization'	14,4 V / 28,8 V (adjustable)
Charging Algorithm	multi-stage adaptive	Current Rating	10
Float Charge Voltage	13,8 V / 27,6 V (adjustable)	Humidity	95 %, non-condensing
Ingress Protection	IP43 (electronic components), IP22 (connection area)	Low voltage load disconnect	11,1 V / 22,2 V / 44,4 V or 11,8 V / 23,6 V / 47,2 V or Battery Life algorithm
Max PV Short Circuit Current (per tracker)	13 A	Max PV Voltage (DC)	75 V
Max. continuous load current	15 A	Max. PV short circuit current	13 A
Nominal PV power, 12 V	145 W	Power terminals	6 mm² / AWG10
Protection	Output short circuit / Over temperature	PV terminals	6 mm² / AWG10
Safety	EN/IEC 62109-1, UL 1741, CSA C22.2	Self-consumption	12 V: 19 mA 24 V: 16 mA
SKU	SM-PWM-VIC-00243	Start Voltage	75
Temperature Compensation Range	-16 mV / °C resp. -32 mV / °C

Notice a wrong or outdated datasheet? Help us fix it.

Freelancers

Verified

Verified Solar Installers for this Product

View All

Ndawula Muhamadi

Hybrid Solar Wholesale Supplier & Installer Expert

Masaka

Solar Installation Solar System Design Solar Energy Audits

View Profile

Osama Mathew

Solar | water pumps | Backup systems

Kampala

Lighting Troubleshooting CAD Design

View Profile

Okitwi Francis

Certified solar technician based in Tororo

Tororo

Solar Installation Inverter Setup Solar System Design

View Profile

Francis Ekapuloni

Professional Solar Expert

Kampala

Solar Installation Solar Energy Audits

View Profile

ANITA

Solar system installation

Kampala

Electrical Repairs Appliance Repair Solar Installation

View Profile

WASSWA Emmy

Solar installer

Bugiri

Electrical Repairs Solar System Design Electrical Installation

View Profile

ETIENE MAATE

ElectroMechanical Engineer

Kampala

Project Management Solar Water heater Solar System Design

View Profile

Tamale Muhamad

Expert Solar Systems Designer & Installer – Powering Your Future!

Kampala

Solar Installation Solar Panel Cleaning Solar Water heater

View Profile

Kibozeeyi John

Skilled Solar Installer – Expertise in Felicity, CWorth, & other quality brands

Kampala

Solar Installation Solar Panel Cleaning Solar System Design

View Profile

Kizito Vincent

I am a technician dealing in hydro and solar power, security systems, networking...

Kampala

IT Support Electrical Repairs Battery Wiring

View Profile

Swipe/scroll to see more →

Description

Specs & details

Overview

The Victron MPPT 75/10 MPPT Charge Controller is engineered for reliable solar charging in low voltage (LV), single phase 12V or 24V systems. With ultra-fast Maximum Power Point Tracking (MPPT) technology, it maximizes energy harvest even under fluctuating light conditions, which is common in Uganda’s climate. Integrated Bluetooth Smart allows for wireless setup, monitoring, and firmware updates via mobile devices. The controller supports intelligent battery management with programmable charging algorithms and features a load output to prevent battery over-discharge. Its robust design includes temperature compensation, short circuit protection, and recovery for fully discharged batteries, ensuring dependable operation in demanding environments. The compact form factor and IP43/IP22 protection ratings make it suitable for residential, small commercial, and rural solar installations.

About this item

BLUETOOTH SMART: Built-in wireless connectivity enables remote setup, monitoring, and updates via the VictronConnect app.
ULTRA-FAST MPPT: Advanced tracking algorithm increases solar energy harvest by up to 30% compared to PWM controllers.
LOAD OUTPUT: Integrated load output disconnects to prevent battery over-discharge, supporting battery longevity.
INTELLIGENT BATTERY MANAGEMENT: Adaptive multi-stage charging and Battery Life algorithm optimize battery health.
TEMPERATURE COMPENSATION: Internal sensor adjusts charging voltages based on ambient temperature for safe operation.
FULLY DISCHARGED BATTERY RECOVERY: Automatically initiates charging on deeply discharged batteries, including Li-ion with disconnect.

Applications

Off-grid solar home systems
Small commercial solar installations
Rural electrification projects
Solar-powered lighting
Telecom and remote monitoring sites

Product FAQs

The controller supports both lead-acid (flooded, AGM, GEL) and lithium batteries with programmable charging algorithms.

Browse live offers Compare models

Yes, Bluetooth Smart connectivity allows wireless monitoring and configuration via the VictronConnect app on smartphones or tablets.

Browse live offers

No, this model is designed for single phase, low voltage (LV) 12V or 24V systems.

Browse live offers Use solar calculator

The maximum PV open circuit voltage is 75V, and the maximum PV short circuit current is 13A.

Browse live offers

Yes, the integrated load output disconnects loads to prevent battery over-discharge based on preset voltages or the Battery Life algorithm.

Browse live offers

Yes, it features a recovery function that initiates charging even if the battery voltage is at zero, including lithium batteries with integrated disconnect.

Browse live offers

Yes, it operates reliably in temperatures from -30°C to +60°C and up to 95% non-condensing humidity, making it suitable for Uganda’s conditions.

Browse live offers
