Victron 12/375 Solar Inverter PSW 375VA 17V for Home solar backup, Small business power, Telecom and ICT
About this item
Product spotlights
Highlights: The Victron 12/375 Solar Inverter PSW delivers 375VA of continuous power in a low voltage (LV), single phase configuration, making it suitable for small-scale solar and backup systems in Uganda. Its pure sine wave output and ECO mode ensure efficient, stable operation for sensitive electronics.
Product Information
Technical specifications| Brand | Victron | Model | 12/375 |
|---|---|---|---|
| Rated Power | 375VA | Nominal Output Frequency | 230VAC or 120VAC +/- 3% 50Hz or 60Hz +/- 0.1% |
| Nominal Voltage | 9.2 - 17 V | Surge Power | 700W |
| Product Dimensions | 86 x 165 x 260 | Product Weight | 2.4 KG |
| Efficiency | 89% | Operating Temperature | range,"-40 to +65°C (fan assisted cooling), Derate 1.25% per °C above 40°C" |
| Battery charged detect (adjustable) | 14.0V | Battery Type | connection,Screw terminals |
| Battery-connection | Screw terminals | Certification | ECE R10-4 |
| Continuous power at 25°C / 40°C | 375VA | DC low restart and alarm (adjustable) | 10.9V |
| DC low shut down (adjustable) | 9.3V | EMC | EN 55014-1 / EN 55014-2 / IEC 61000-6-1 / IEC 61000-6-2 / IEC 61000-6-3 |
| Humidity | condensing),max 95% | Humidity (non-condensing) | max 95% |
| Ingress Protection | IP 21 | Input AC Voltage Range | 9.2 - 17V |
| Integrated Transfer switch | Filax | Material | & Colour,Steel chassis and plastic cover (blue Ral 5012) |
| Material & Colour | Steel chassis and plastic cover (blue Ral 5012) | Maximum cable cross-section | 10mm² / AWG8 |
| Protection | IP 21 | Remote On/Off | Yes |
| Safety | standards,EN-IEC 60335-1 / EN-IEC 62109-1 / UL 458 | Safety Standard | EN-IEC 60335-1 / EN-IEC 62109-1 / UL 458 |
| SKU | 111 | Standard AC outlets | 230V: Schuko (CEE 7/4), IEC-320 (male plug included); 120V: Nema 5-15R, GFCI |
| Start Voltage | 17 | Zero load power (W) | 5.6W |
| Zero load power in AES mode (W) | 0.9W |
Notice a wrong or outdated datasheet? Help us fix it.
Freelancers
VerifiedVerified Solar Installers for this Product
View All
WASSWA Emmy
Solar installer
Bugiri
Electrical Repairs
Solar System Design
Electrical Installation
View Profile
Osama Mathew
Solar | water pumps | Backup systems
Kampala
Lighting
Troubleshooting
CAD Design
View Profile
Ndawula Muhamadi
Hybrid Solar Wholesale Supplier & Installer Expert
Masaka
Solar Installation
Solar System Design
Solar Energy Audits
View Profile
Kibozeeyi John
Skilled Solar Installer – Expertise in Felicity, CWorth, & other quality brands
Kampala
Solar Installation
Solar Panel Cleaning
Solar System Design
View Profile
Okitwi Francis
Certified solar technician based in Tororo
Tororo
Solar Installation
Inverter Setup
Solar System Design
View Profile
Tamale Muhamad
Expert Solar Systems Designer & Installer – Powering Your Future!
Kampala
Solar Installation
Solar Panel Cleaning
Solar Water heater
View Profile
Kizito Vincent
I am a technician dealing in hydro and solar power, security systems, networking...
Kampala
IT Support
Electrical Repairs
Battery Wiring
View Profile
ETIENE MAATE
ElectroMechanical Engineer
Kampala
Project Management
Solar Water heater
Solar System Design
View Profile
ANITA
Solar system installation
Kampala
Electrical Repairs
Appliance Repair
Solar Installation
View Profile
Francis Ekapuloni
Professional Solar Expert
Kampala
Solar Installation
Solar Energy Audits
View Profile
Swipe/scroll to see more →
Description
Specs & detailsOverview
The Victron 12/375 Solar Inverter PSW is engineered for reliable power conversion in off-grid and backup solar
About this item
- PURE SINE WAVE OUTPUT: Delivers stable AC power suitable for sensitive electronics and appliances.
- LOW VOLTAGE (LV) SINGLE PHASE: Operates on 12V DC input, ideal for small-scale solar systems in Uganda.
- ECO MODE: Adjustable settings reduce zero-load power consumption for greater energy efficiency.
- PEAK POWER CAPACITY: Handles surges up to 700W, supporting startup of demanding devices.
- ROBUST PROTECTION: Includes configurable DC cut-off, overload, and temperature safeguards.
- MULTIPLE AC OUTLET OPTIONS: Supports Schuko, IEC-320, Nema 5-15R, and GFCI for flexible connectivity.
Applications
- Home solar backup systems
- Small business power solutions
- Telecom and ICT equipment
- Mobile and portable solar setups
- Rural electrification projects
Product FAQs
The Victron 12/375 operates as a low voltage (LV), single phase inverter, suitable for 12V DC battery systems.
Yes, the pure sine wave output ensures compatibility with sensitive electronics and appliances.
It provides 375VA continuous power and can handle peak loads up to 700W.
Yes, ECO mode settings can be adjusted to optimize zero-load power consumption.
The inverter supports Schuko, IEC-320, Nema 5-15R, and GFCI AC outlets.
Yes, it includes configurable DC cut-off, overload, and temperature protection.
Yes, remote on-off functionality is supported for flexible system integration.
