Victron 450|200 MPPT Charge Controller 48V HV for Large residential, Commercial and, Off-grid and hybrid

Name: Victron 450|200 48V HV MPPT Charge Controller | Best Price Uganda
Brand: victron
SKU: SM-MPP-VIC-00255
Price: 8250000.00 UGX
Availability: InStock

victron

0 out of 5 | 0 Ratings | Q&A

About this item

Product spotlights

Highlights: The Victron 450|200 MPPT Charge Controller is a high-voltage solar charge controller designed for large-scale energy systems. Its core benefit is maximizing solar energy harvest from high-voltage arrays to efficiently charge 48V battery banks. It is compatible with 48V battery systems and features a 450V maximum PV input, 200A charge current, and 11.5kW power handling.

UGX9,075,000

Variation

10 available

Minimum order qty 1

QTY

Order on WhatsApp

Selected Product Summery

Victron 450|200 MPPT Charge Controller 48V HV for Large residential, Commercial and, Off-grid and hybrid -

Compare With Similar capacity MPPT Charge Controllers

Sold by Masrcorp Solar Uganda

Message Seller

Brand victron

Products from this brand

Product Information

Technical specifications

Brand	Victron	Model	450\|200 MPPT
Max Charging Current	200	MPPT Voltage Range	65 – 450
Nominal Voltage	48	Number of MPPT Trackers	4
Product Dimensions	487 x 434 x 146mm	Product Weight	13.7KG
Communication	VE.Direct port, VE.Can port & Bluetooth (6)	Efficiency	96
Absorption Voltage	57.6V (adjustable)	Battery-connection	4x M8 bolts, 2x positive and 2x negative
Charging Algorithm	Multi-stage adaptive (adjustable)	Country of Origin	Designed in The Netherlands made in India
Float Charge Voltage	55.2V (adjustable)	General purpose analogue/digital in port	Yes, 2x
Humidity	max 95 %	Material & Colour	steel, blue RAL 5012
Max PV Array Size Per Tracker	7200 Wp (450V x 20A)	Max PV Short Circuit Current (per tracker)	20A per tracker
Max PV Voltage (DC)	450	Maximum Charge Power	4000W per tracker 11520W total
Parallel Operation	25 units with VE.Can	Programmable Relay	Yes
Protection	PV reverse polarity Output short circuit Over temperature	Protection Category (IP)	IP21
PV Isolation Fail Level	100	PV Start-up Voltage	120
Remote On/Off	Yes	Safety	EN-IEC 62109-1
Self-consumption	15	SKU	SM-MPP-VIC-00255
Temperature Compensation Range	-40 to +60 °C (fan assisted cooling)

Notice a wrong or outdated datasheet? Help us fix it.

Freelancers

Verified

Verified Solar Installers for this Product

View All

Osama Mathew

Solar | water pumps | Backup systems

Kampala

Lighting Troubleshooting CAD Design

View Profile

Francis Ekapuloni

Professional Solar Expert

Kampala

Solar Installation Solar Energy Audits

View Profile

WASSWA Emmy

Solar installer

Bugiri

Electrical Repairs Solar System Design Electrical Installation

View Profile

ETIENE MAATE

ElectroMechanical Engineer

Kampala

Project Management Solar Water heater Solar System Design

View Profile

Ndawula Muhamadi

Hybrid Solar Wholesale Supplier & Installer Expert

Masaka

Solar Installation Solar System Design Solar Energy Audits

View Profile

Kibozeeyi John

Skilled Solar Installer – Expertise in Felicity, CWorth, & other quality brands

Kampala

Solar Installation Solar Panel Cleaning Solar System Design

View Profile

MWESIGWA JOEL BALINNYA

An experienced electrical technician for solar energy and grid LV (240V) domesti...

ENTEBBE

Electrical Design Data Entry Electrical Repairs

View Profile

Tamale Muhamad

Expert Solar Systems Designer & Installer – Powering Your Future!

Kampala

Solar Installation Solar Panel Cleaning Solar Water heater

View Profile

Kizito Vincent

I am a technician dealing in hydro and solar power, security systems, networking...

Kampala

IT Support Electrical Repairs Battery Wiring

View Profile

ANITA

Solar system installation

Kampala

Electrical Repairs Appliance Repair Solar Installation

View Profile

Swipe/scroll to see more →

Description

Specs & details

Overview

HV configuration. The Victron 450|200 MPPT Charge Controller is engineered for demanding solar applications in Uganda, supporting 48V low voltage (LV) battery banks and delivering up to 200A of charge current. Its four independent MPPT trackers allow for optimal energy harvest from multiple PV arrays, making it suitable for both residential and commercial systems. The controller features a multi-stage adaptive charging algorithm, programmable voltage settings, and integrated battery temperature sensing to ensure safe and efficient operation. With robust protection features, remote monitoring via Bluetooth, and synchronised parallel operation capability, this unit is designed to meet the needs of complex off-grid and hybrid solar projects. The steel enclosure and IP21 rating provide durability in varied Ugandan environments.

About this item

SYSTEM TOPOLOGY: HV architecture for compliant solar system design.
FOUR MPPT TRACKERS: Enables simultaneous tracking of multiple PV arrays for improved energy yield.
HIGH CHARGE CURRENT: Supports up to 200A charging for large 48V battery banks in LV systems.
MULTI-STAGE CHARGING: Adaptive algorithm optimizes battery health and performance.
ADVANCED COMMUNICATION: Includes VE.Direct, VE.Can, and Bluetooth for flexible monitoring and integration.
PARALLEL OPERATION: Synchronises with up to 25 units for scalable system expansion.

Product FAQs

Victron 450|200 MPPT Charge Controller 48V HV for Large residential, Commercial and, Off-grid and hybrid is rated at 48V. Keep continuous loads within this rating for stable operation.

Browse live offers

Victron 450|200 MPPT Charge Controller 48V HV for Large residential, Commercial and, Off-grid and hybrid is configured for 48V systems. Match battery bank voltage to this value for safe operation.

Browse live offers Compare models Use solar calculator

MPPT/charge limit is 48V. PV input limit is 48V. Design array and charging settings within these limits.

Browse live offers

Confirm phase type from the datasheet and validate against your site distribution setup.

Browse live offers

Compare rated output (48V), system voltage (48V), charge limit (48V), and PV limit (48V) side by side before selecting the best offer.

Browse live offers Compare models
