Felicity IVCM1012 LV 1kW Hybrid Inverter, 105V, For Small home backup, Lighting, 12V

Name: Felicity IVCM1012 LV 1kW Hybrid Inverter, 105V, For Small home backup, Lighting, 12V
Brand: Felicity
SKU: SM-HYB-FEL-00841
Price: 808500.00 UGX
Availability: InStock

Felicity

0 out of 5 | 0 Ratings | Q&A

About this item

Product spotlights

Highlights: Felicity IVCM1012 LV is a 1kW 105V hybrid inverter in Uganda. It supports up to 800W PV input and is built for Small home backup, Lighting, Router, TV where battery-backed continuity and stable AC output matter

UGX808,500 /Pcs

1 Days

VAT incl.

2 available

Minimum order qty 1

QTY

Order on WhatsApp

Compare With Similar capacity Hybrid Inverters

Estimate Shipping Time 1 Days

Sold by Masrcorp Solar Uganda

Message Seller

Brand Felicity

Products from this brand

Product Information

Technical specifications

Brand	Felicity	Model	IVCM1012 LV
Rated Power	1000VA/1000W	Max PV Input Power	800 W
Max Charging Current	60 A	MPPT Voltage Range	Range (V),15-90V
Max PV Open Circuit Voltage	105 V	Nominal Output Voltage	(V),120V±5%
Nominal Output Frequency	(Hz),50±0.3Hz/60Hz±0.3Hz (Auto detection)	Nominal Voltage	65-140 V
Product Dimensions	422x330x181mm	Product Weight	5.5 KG
Waveform	Pure sine wave	Efficiency	90%
Operating Temperature	Range,-10°C ~55°C	AC Output Rated Current	10 A
Battery Type	Lithium	Charging Algorithm	Three stage
Chemistry	Lithium	Current Rating	10
DC low shut down (adjustable)	@ Load < 20%	High DC Input Alarm & Fault	30 V
High Line Voltage Disconnect	140Vac±3V	Input AC Voltage Range	(V),65-140Vac
Low DC Input Shut-down Recovery	29 V	Low voltage load disconnect	40±1Hz
Max AC Input Voltage	140Vac±3V	Max PV Input Current	35 A
Max. AC Input/Output Apparent Power (VA)	14 A	Max. Bypass Overload Current	14 A
Max. Shorted Current	10A/1000W	Output Short Circuit Protection	Yes
Overcharge Protection	Yes	Rated AC Input/Output Active Power (W)	1000 W
SKU	SM-HYB-FEL-00841	Start Voltage	23 V
Storage Temperature	-15°C ~60°C	Transfer Time	10ms typical (UPS); 20ms typical (Appliances)

Notice a wrong or outdated datasheet? Help us fix it.

Freelancers

Verified

Verified Solar Installers for this Product

View All

Ndawula Muhamadi

Hybrid Solar Wholesale Supplier & Installer Expert

Masaka

Solar Installation Solar System Design Solar Energy Audits

View Profile

Kibozeeyi John

Skilled Solar Installer – Expertise in Felicity, CWorth, & other quality brands

Kampala

Solar Installation Solar Panel Cleaning Solar System Design

View Profile

Tamale Muhamad

Expert Solar Systems Designer & Installer – Powering Your Future!

Kampala

Solar Installation Solar Panel Cleaning Solar Water heater

View Profile

Okitwi Francis

Certified solar technician based in Tororo

Tororo

Solar Installation Inverter Setup Solar System Design

View Profile

ETIENE MAATE

ElectroMechanical Engineer

Kampala

Project Management Solar Water heater Solar System Design

View Profile

WASSWA Emmy

Solar installer

Bugiri

Electrical Repairs Solar System Design Electrical Installation

View Profile

ANITA

Solar system installation

Kampala

Electrical Repairs Appliance Repair Solar Installation

View Profile

Francis Ekapuloni

Professional Solar Expert

Kampala

Solar Installation Solar Energy Audits

View Profile

Osama Mathew

Solar | water pumps | Backup systems

Kampala

Lighting Troubleshooting CAD Design

View Profile

Kizito Vincent

I am a technician dealing in hydro and solar power, security systems, networking...

Kampala

IT Support Electrical Repairs Battery Wiring

View Profile

Swipe/scroll to see more →

Description

Specs & details

Overview

Felicity IVCM1012 LV is a 1kW 105V hybrid inverter for Uganda power conditions. It supports up to 800W PV input and is suitable for Small home backup, Lighting, Router, TV where dependable backup and solar charging are required. Buyers should also confirm the datasheet limits, warranty coverage, seller authenticity, and installer compatibility before ordering

About this item

POWER RATING: 1kVA/1000W output capacity for small backup and solar hybrid systems.
BATTERY SYSTEM: 12V lithium battery compatibility for compact energy storage setups.
OUTPUT WAVEFORM: Pure sine wave output for sensitive electronics and mixed household loads.
CHARGING ARCHITECTURE: Hybrid charging support from solar and grid sources with three-stage battery charging.
SOLAR INPUT WINDOW: PV operating range of 15-90V with 105V maximum open-circuit voltage and 800W maximum input power.
SYSTEM RESPONSE: Typical transfer time of 10ms in UPS mode and 20ms in appliance mode for load continuity.

Applications

Small home backup power systems
Lighting and entertainment circuits
Router, TV, and decoder backup
Small office essential loads
Solar hybrid systems with lithium batteries
Sites needing compact 12V inverter storage

Compatibility

Compatible with any brand

For more information please contact our technical team. Some models within the listed brands may be incompatible even if the brand is officially supported.

Product FAQs

Felicity IVCM1012 LV is a 1kW hybrid inverter in Uganda. Key specs include battery voltage range 12V, max PV input voltage 105V, max PV input power 800W, rated AC output 1kW.

Browse live offers

For Felicity IVCM1012 LV, use MPPT/operating voltage range 15-90V, max PV input voltage 105V, and max PV input power 800W when designing strings.

Browse live offers Find technicians

Felicity IVCM1012 LV allows up to 800W PV input power. Use max PV input voltage 105V for string sizing checks.

Browse live offers

Felicity IVCM1012 LV is built for 12V battery systems. The battery voltage range is 12V, with maximum charging current the listed charging current and maximum discharging current 10A.

Browse live offers

Felicity IVCM1012 LV has a rated AC output of 1kW. It operates with the listed grid frequency and AC voltage range 110/120Vac. If needed, use 140Vac±3V for compatibility checks.

Browse live offers Request quotes Find technicians

Compare verified seller pricing, warranty terms, authenticity, and installer support for Felicity IVCM1012 LV. Also match battery voltage range, MPPT layout, max PV input voltage, communication, monitoring, AC output, and warranty against the datasheet.
