SRNE 12kW Hybrid Inverter for Home and Small Business Backup 48V 230/400VAC Three-Phase Dual MPPT 200-650VDC 260A Hybrid Charging Expandable to 6 Units IP65 5-Year Warranty (HESP48120H3)
⇄ Compare ♡ Save ↗ Share ⬇ Specs (CSV)
SRNE · Hybrid Inverters

SRNE 12kW Hybrid Inverter for Home and Small Business Backup 48V 230/400VAC Three-Phase Dual MPPT 200-650VDC 260A Hybrid Charging Expandable to 6 Units IP65 5-Year Warranty (HESP48120H3)

UGX7,474,060
☆☆☆☆☆ No reviews yet ·Questions (0)
App price · Save UGX149,481Delivery in 7 days1-yr warranty
Sold by
Masrcorp Solar Uganda ✓
Delivery in 7 days · 10 In stock
UGX7,474,060
Want another price?Only one shop lists this right now. Send one request and other shops reply with their prices.
Similar products from other shops
SRNE 12kW Hybrid Inverter for Three-Phase Commercial Backup 48V 230/400Vac Dual MPPT 800Vdc 6-Parallel RS485/CAN (ASP48120H3) SRNE 12kW Hybrid Inverter for Three-Phase Commercial Backup 48V 230/40... UGX8,045,400 BLISON ENERGY SRNE 12kW 24kVA Max Surge Hybrid Inverter for Home and Small Business Backup 48Vdc 230Vac Single-Phase Dual MPPT 125-425Vdc Parallel up to 6 Units IP20 Indoor (ASP48120S200-H) SRNE 12kW 24kVA Max Surge Hybrid Inverter for Home and Small Business... UGX8,946,718 BLISON ENERGY SRNE 10kW Single Phase Hybrid Inverter for Home solar backup and Small business power 48V Battery MPPT 425V 2-Year Warranty (ASP48100S200-H) SRNE 10kW Single Phase Hybrid Inverter for Home solar backup and Small... UGX6,879,400 BLISON ENERGY SRNE 6kW Hybrid Inverter for Home and Small Business Backup 48V 230VAC Dual MPPT 120-450VDC Expandable to 6 Units IP65 5-Year Warranty (HESP4860S100-H) SRNE 6kW Hybrid Inverter for Home and Small Business Backup 48V 230VAC... UGX5,669,092 BLISON ENERGY
Ways to payAll options
Pay NowBank Transfer
Warranty and returns
Warranty
1 year · this product
Returns
7 Days · unused and not installed.
Refund
Replacement only
The warranty is this product's own (1 year). Returns and refunds follow Masrcorp Solar Uganda's signed policy. If the shop doesn't reply to a claim in 48 hours, SolarMarket steps in.
Complete your systemMatched to 48 V
Solar Panels
UGX429,000
Battery
UGX2,862,000
Cables, mounting and protection
UGX49,809
With this product:
Technicians who install this
View All
Swipe/scroll to see more →
Key specs
Brand SRNE Rated Power 12,000W
Max PV Input Power 9,000W+9,000W Max Charging Current 120A
MPPT Voltage Range 200-650Vdc/200-650Vdc Max PV Open Circuit Voltage 800Vdc+800Vdc
Nominal Output Voltage 230/400 Vac（three-Phase） Nominal Output Frequency 50/60Hz ±0.3
Nominal Voltage 48 V Number of MPPT Trackers 2
Product Dimensions 670*440*240 mm Product Weight 39 KG
Communication RS485/CAN/USB/Dry Contact Efficiency ≥92%
Warranty 5 years Battery Type Li-ion / Lead-Acid / User Defined
Chemistry Lead-acid Current Rating 260 A
Discharging time 10ms（typical） Energy 6HP
Ingress Protection IP65 Input AC Voltage Range 50/60Hz
Load Motor Capacity 6HP Max PV Input Current 22A+22A
Max. AC Input/Output Apparent Power (VA) 24,000VA Max. Bypass Overload Current 35A
Max. Parallel Capacity 1～6 Units Protection Degree,IP65
Rated AC Input/Output Active Power (W) 12,000W SKU SM-HYB-SRN-01324
Temperature Rating -10~55℃, >45℃ Derate

Notice a wrong or outdated datasheet? Help us fix it.

About this product

Overview

SRNE HESP48120H3 is a 12kW 48V Three Phase hybrid inverter for Uganda power conditions. It supports up to 9kW PV input and is suitable for Home backup power, Small business, Off-grid or hybrid where dependable backup and solar charging are required. Buyers should also confirm the datasheet limits, warranty coverage, seller authenticity, and installer compatibility before ordering

About this item

  • SYSTEM TOPOLOGY: Three Phase architecture for compliant solar system design.
  • RATED OUTPUT POWER: 12,000W continuous output with 24, peak capacity, suitable for running heavy loads in a three-phase home or small business.
  • THREE-PHASE OUTPUT: Delivers 230/400VAC three-phase power at 50/60Hz, compatible with standard three-phase electrical systems in Uganda.
  • DUAL MPPT TRACKERS: Two independent MPPT inputs each support up to 9,000W solar array power, with a voltage range of 200-650VDC and 99.9% tracking efficiency.
  • HIGH HYBRID CHARGING CURRENT: Up to 260A combined charging from grid/generator and solar, with a dedicated 120A grid/generator charger for fast battery replenishment.
  • IP65 PROTECTION: Weatherproof enclosure rated IP65, allowing installation outdoors or in dusty environments without additional shelter.

What's Included

  • SRNE HESP48120H3 Hybrid Inverter unit
  • User manual and installation guide
  • Communication cable (RS485/CAN)
  • Mounting brackets and hardware
  • Warranty card (5 years)

Applications

  • Home backup power for three-phase electrical systems
  • Small business and shop backup in areas with unreliable grid
  • Off-grid or hybrid solar installations requiring three-phase output
  • Water pumping and irrigation systems with three-phase motors
  • Commercial refrigeration and cold storage backup
Ask Volta about this“Will it run my fridge and pump overnight?”
Chat with Volta
Frequently Asked Questions
What are the key specs of SRNE HESP48120H3 in Uganda?
SRNE HESP48120H3 is a 12kW Three Phase hybrid inverter in Uganda. Key specs include battery voltage range 48V, max PV input voltage 800Vdc+800Vdc, max PV input power 9kW, rated AC output 12kW, communication RS485/CAN, warranty 5 years.
What PV voltage limits should technicians use for SRNE HESP48120H3?
For SRNE HESP48120H3, use MPPT/operating voltage range 200-650Vdc/200-650Vdc, max PV input voltage 800Vdc+800Vdc, and max PV input power 9kW when designing strings.
How much solar PV can be connected to SRNE HESP48120H3?
SRNE HESP48120H3 allows up to 9kW PV input power. Use MPPT range 200-650Vdc/200-650Vdc, max PV input voltage 800Vdc+800Vdc for string sizing checks.
What battery and charge current settings apply to SRNE HESP48120H3?
SRNE HESP48120H3 is built for 48V battery systems. The battery voltage range is 48V, with maximum charging current 22A+22A.
What AC output should buyers and installers expect from SRNE HESP48120H3?
SRNE HESP48120H3 has a rated AC output of 12kW on Three Phase output. It operates with grid frequency the listed grid frequency and AC voltage range 230/400 Vac（three-Phase）. If needed, use Phase voltage 170~280V, Line voltage 305~485V for compatibility checks.
What should buyers compare before ordering SRNE HESP48120H3 in Uganda?
Compare verified seller pricing, warranty terms, authenticity, and installer support for SRNE HESP48120H3. Also match battery voltage range, MPPT layout, max PV input voltage, communication, monitoring, AC output, and warranty against the datasheet.
