Victron 12/3000/120 Inverter Charger 12V Three Phase for Residential solar, Commercial and, Off-grid homes and
⇄ Compare ♡ Save ↗ Share ⬇ Specs (CSV)
victron · Inverter Chargers

Victron 12/3000/120 Inverter Charger 12V Three Phase for Residential solar, Commercial and, Off-grid homes and

UGX8,202,810
☆☆☆☆☆ No reviews yet ·Questions (0)
App price · Save UGX164,056Delivery in 7 days1-yr warranty
Sold by
Masrcorp Solar Uganda ✓
Delivery in 7 days · In stock
UGX8,202,810
Want another price?Only one shop lists this right now. Send one request and other shops reply with their prices.
Similar products from other shops
SRNE 12kW 24kVA Max Surge Hybrid Inverter for Home and Small Business Backup 48Vdc 230Vac Single-Phase Dual MPPT 125-425Vdc Parallel up to 6 Units IP20 Indoor (ASP48120S200-H) SRNE 12kW 24kVA Max Surge Hybrid Inverter for Home and Small Business... UGX8,946,718 BLISON ENERGY SRNE 12kW Hybrid Inverter for Three-Phase Commercial Backup 48V 230/400Vac Dual MPPT 800Vdc 6-Parallel RS485/CAN (ASP48120H3) SRNE 12kW Hybrid Inverter for Three-Phase Commercial Backup 48V 230/40... UGX8,045,400 BLISON ENERGY SRNE 10kW Single Phase Hybrid Inverter for Home solar backup and Small business power 48V Battery MPPT 425V 2-Year Warranty (ASP48100S200-H) SRNE 10kW Single Phase Hybrid Inverter for Home solar backup and Small... UGX6,879,400 BLISON ENERGY SRNE 6kW Hybrid Inverter for Home and Small Business Backup 48V 230VAC Dual MPPT 120-450VDC Expandable to 6 Units IP65 5-Year Warranty (HESP4860S100-H) SRNE 6kW Hybrid Inverter for Home and Small Business Backup 48V 230VAC... UGX5,669,092 BLISON ENERGY
Ways to payAll options
Pay NowBank Transfer
Warranty and returns
Warranty
1 year · this product
Returns
7 Days · unused and not installed.
Refund
Replacement only
The warranty is this product's own (1 year). Returns and refunds follow Masrcorp Solar Uganda's signed policy. If the shop doesn't reply to a claim in 48 hours, SolarMarket steps in.
Complete your systemMatched to 12 V
Solar Panels
UGX429,000
Battery
UGX1,019,520
Cables, mounting and protection
UGX11,500
With this product:
Technicians who install this
View All
Swipe/scroll to see more →
Key specs
Brand Victron Model 12/3000/120
Rated Power 3000 VA Max Charging Current 120 / 70 / 35 A
Nominal Output Voltage 230 VAC ± 2 % Nominal Output Frequency 50 Hz ± 0,1 %
Nominal Voltage 187 -250 V Surge Power 6000 W
Product Dimensions 375 x 214 x 110 mm Product Weight 10 KG
Communication For parallel and three phase operation, remote monitoring and system integration Efficiency 93 / 94 / 95%
Operating Temperature -40 to +65 °C (fan assisted cooling) Absorption Voltage 14,4 / 28,8 / 57,6 V
Auxiliary output Yes (16A) Battery Type connection,Four M8 bolts (2 plus and 2 minus connections)
Battery-connection Four M8 bolts (2 plus and 2 minus connections) Continuous power at 25°C / 40°C 2400 W
Current Rating 120 A Enclosure Material & Colour aluminium (blue RAL 5012)
General purpose analogue/digital in port Yes Humidity condensing),max 95 %
Humidity (non-condensing) max 95 % Ingress Protection a - g
Integrated Transfer switch 16 A Material & Colour aluminium (blue RAL 5012)
Max AC Input Voltage Input voltage range: 187 -250 V Input frequency: 50/60 Hz Cos Φ >0.8 Max PV Input Current 250 A
Maximum input voltage 9,5 – 17 V Maximum output current 11 A
Peak Current (15s) 250 Permissible Altitude 2000 m.
Power Factor ±0.8 PowerControl / PowerAssist Yes
Programmable Relay Yes Protection a - g
Remote On/Off Yes Safety EN-IEC 60335-1, EN-IEC 60335-2-29, IEC 62109-1
Safety Standard EN-IEC 60335-1, EN-IEC 60335-2-29, IEC 62109-1 SKU 201
Storage Temperature Being checked Transfer Time 16 A
Zero load power (W) W),20 / 20 / 25 Zero load power in AES mode (W) W),15 / 15 / 20

Notice a wrong or outdated datasheet? Help us fix it.

About this product

Overview

The Victron 12/3000/120 Inverter Charger is engineered for 12V low voltage (LV) single phase installations, providing a continuous 3kVA (2400W) output and robust peak power handling. Designed for both off-grid and backup power scenarios in Uganda, it features advanced PowerAssist and PowerControl technologies to manage generator or grid input and prevent overloads. The unit supports seamless AC transfer with a 16A transfer switch and offers high efficiency operation, with multiple programmable settings for system integration. VE.Bus communication enables parallel or three phase expansion and remote monitoring, making it suitable for a wide range of residential, commercial, and mobile energy systems. The inverter charger is protected to IP20 standards and operates reliably across a wide temperature range, ensuring durability in diverse Ugandan environments.

About this item

  • SYSTEM TOPOLOGY: Three Phase architecture for compliant solar system design.
  • POWERASSIST TECHNOLOGY: Actively prevents overload of limited AC sources by boosting capacity with battery power.
  • POWERCONTROL FUNCTION: Automatically manages battery charging and AC loads to avoid exceeding generator or grid limits.
  • PURE SINE WAVE OUTPUT: Delivers stable 230V AC ±2% for sensitive electronics and appliances.
  • VE.BUS COMMUNICATION: Supports parallel, three phase operation, and remote system integration for flexible setups.
  • PROGRAMMABLE RELAY & AUXILIARY OUTPUT: Allows custom automation and control for advanced energy management.

Applications

  • Residential solar backup systems
  • Commercial and institutional backup power
  • Off-grid homes and lodges
  • Mobile power for vehicles and boats (12V systems)
  • Telecom and remote site power solutions
Ask Volta about this“Will it run my fridge and pump overnight?”
Chat with Volta
Frequently Asked Questions
What voltage class and phase does the Victron 12/3000/120 support?
This model is designed for 12V low voltage (LV) battery systems and single phase 230V AC output.
Can this inverter charger be used in parallel or three phase systems?
Yes, the VE.Bus communication port allows for parallel and three phase operation with compatible Victron units.
Is the Victron 12/3000/120 suitable for off-grid applications in Uganda?
Yes, it is well-suited for off-grid and backup power needs, supporting reliable operation in diverse Ugandan environments.
What battery types are compatible with this inverter charger?
It supports 12V lead-acid and lithium battery banks. Ensure battery specifications match the charger's requirements.
Does the unit provide protection against overload and short circuit?
Yes, it includes multiple protection features such as overload, short circuit, and over-temperature safeguards.
Can I monitor and control the inverter remotely?
Remote monitoring and control are possible via the VE.Bus port and compatible Victron remote management solutions.
What is the maximum continuous output power?
The inverter delivers up to 3kVA (2400W) continuous output at 25°C.
