Cworth 6kW High Voltage Hybrid Inverter for Home and Small Business Backup 48V 230VAC Output 500V PV Open Circuit Dual MPPT 120A Charge 12-Unit Parallel Expandable (CE-H6K)

Name: Cworth 6kW High Voltage Hybrid Inverter for Home and Small Business Backup 48V 230VAC Output 500V PV Open Circuit Dual MPPT 120A Charge 12-Unit Parallel Expandable (CE-H6K)
Brand: Cworth
SKU: SM-CAT-GEN-00930
Price: 3289000.00 UGX
Availability: InStock

Cworth

0 out of 5 | 0 Ratings | Q&A

About this item

Product spotlights

Highlights: Cworth CE-H6K is a 6kW 500V hybrid inverter in Uganda. It supports up to 6kW PV input and is built for Home backup power, Small business power, Off-grid solar where battery-backed continuity and stable AC output matter

UGX3,146,000

50 available

Minimum order qty 1

QTY

Order on WhatsApp

Compare With Similar capacity Hybrid Inverters

Sold by Cworth Energy

Message Seller

Brand Cworth

Products from this brand

Product Information

Technical specifications

Brand	SMA	Model	CE-H6K
Rated Power	6000 W	Max PV Input Power	6000W
Max Charging Current	10A-Max. Grid Charge Curent (Adjustable unit is 1A)	MPPT Voltage Range	85V-450V
Max PV Open Circuit Voltage	500 V	Nominal Output Voltage	230Vact5%
Nominal Output Frequency	(Hz),50+0.3Hz/60Hz+0.3Hz (Adjustable)	Nominal Voltage	85 V
Product Dimensions	347x445x120mm	Product Weight	13 KG
Waveform	Pure sine wave	Efficiency	93%
Operating Temperature	Range,-10°C~55°C	AC Output Rated Current	27.3A
Battery Type	AGM	Chemistry	Lithium
Current Rating	27.3	High DC Input Alarm & Fault	62V+0.4V
High Line Voltage Disconnect	280Vact+3V	Input AC Voltage Range	85 V
Low DC Input Shut-down Recovery	60V+0.4V	Low voltage load disconnect	170Vac+3V (For Computers)
Max PV Input Current	27A	Max. AC Input/Output Apparent Power (VA)	6000W
Max. PV short circuit current	170Vac+3V (For Computers)	Max. Shorted Current	27.3A/6000W
Output Short Circuit Protection	Yes	Overcharge Protection	Yes
Parallel Capability	Yes,up to 12 units	Pass Through Without Battery	Yes
Rated AC Input/Output Active Power (W)	6000W	Self Discharge	Adjustable, up to 30V/60V
SKU	SM-CAT-GEN-00930	Start Voltage	48
Storage Temperature	-15°C~60°C	Transfer Time	10ms typical (UPS);20ms typical (Appliances)

Notice a wrong or outdated datasheet? Help us fix it.

Freelancers

Verified

Verified Solar Installers for this Product

View All

Osama Mathew

Solar | water pumps | Backup systems

Kampala

Lighting Troubleshooting CAD Design

View Profile

Ndawula Muhamadi

Hybrid Solar Wholesale Supplier & Installer Expert

Masaka

Solar Installation Solar System Design Solar Energy Audits

View Profile

Tamale Muhamad

Expert Solar Systems Designer & Installer – Powering Your Future!

Kampala

Solar Installation Solar Panel Cleaning Solar Water heater

View Profile

Kibozeeyi John

Skilled Solar Installer – Expertise in Felicity, CWorth, & other quality brands

Kampala

Solar Installation Solar Panel Cleaning Solar System Design

View Profile

Kizito Vincent

I am a technician dealing in hydro and solar power, security systems, networking...

Kampala

IT Support Electrical Repairs Battery Wiring

View Profile

ANITA

Solar system installation

Kampala

Electrical Repairs Appliance Repair Solar Installation

View Profile

Francis Ekapuloni

Professional Solar Expert

Kampala

Solar Installation Solar Energy Audits

View Profile

ETIENE MAATE

ElectroMechanical Engineer

Kampala

Project Management Solar Water heater Solar System Design

View Profile

WASSWA Emmy

Solar installer

Bugiri

Electrical Repairs Solar System Design Electrical Installation

View Profile

Okitwi Francis

Certified solar technician based in Tororo

Tororo

Solar Installation Inverter Setup Solar System Design

View Profile

Swipe/scroll to see more →

Description

Specs & details

Overview

Cworth CE-H6K is a 6kW 500V hybrid inverter for Uganda power conditions. It supports up to 6kW PV input and is suitable for Home backup power, Small business power, Off-grid solar where dependable backup and solar charging are required. Buyers should also confirm the datasheet limits, warranty coverage, seller authenticity, and installer compatibility before ordering

About this item

RATED OUTPUT POWER: 6000W continuous output at 230VAC with pure sine wave waveform, suitable for powering home appliances and small business equipment.
BATTERY COMPATIBILITY: Supports AGM, flooded, and lithium battery types with adjustable charge voltages up to 60V, allowing flexible energy storage choices.
SOLAR CHARGING: Maximum PV input power of 6000W with 120A solar charging current, enabling efficient solar energy harvesting from panels up to 500V open circuit voltage.
PARALLEL OPERATION: Expandable to up to 12 units in parallel for increased power capacity, ideal for scaling your solar system as energy demands grow.
TRANSFER TIME: 10ms typical transfer time in UPS mode and 20ms for appliances, ensuring minimal disruption during grid or generator power loss.
PASS THROUGH WITHOUT BATTERY: The inverter can operate in line mode without a connected battery, providing flexibility for installations where battery storage is not yet available.

What's Included

Cworth CE-H6K Hybrid Inverter unit
User manual
Mounting brackets
Warranty card

Applications

Home backup power during grid outages
Small business power backup for computers and lighting
Off-grid solar systems with battery storage
Grid-tied solar systems with battery backup
Remote telecommunications equipment power

Product FAQs

Cworth CE-H6K is a 6kW hybrid inverter in Uganda. Key specs include battery voltage range 48V, max PV input voltage 500V, max PV input power 6kW, rated AC output 6kW.

Browse live offers

For Cworth CE-H6K, use MPPT/operating voltage range 85V-450V, max PV input voltage 500V, and max PV input power 6kW when designing strings.

Browse live offers Find technicians

Cworth CE-H6K allows up to 6kW PV input power. Use MPPT range 85V-450V, max PV input voltage 500V for string sizing checks.

Browse live offers

Cworth CE-H6K is built for 48V battery systems. The battery voltage range is 48V, with maximum charging current 120A.

Browse live offers

Cworth CE-H6K has a rated AC output of 6kW. It operates with grid frequency 50/60Hz (Auto detection) and AC voltage range 230Vact5%. If needed, use the listed input range for compatibility checks.

Browse live offers Request quotes Find technicians

Compare verified seller pricing, warranty terms, authenticity, and installer support for Cworth CE-H6K. Also match battery voltage range, MPPT layout, max PV input voltage, communication, monitoring, AC output, and warranty against the datasheet.

Browse live offers Compare models Request quotes
