Growatt · Off-Grid Inverters

Growatt SPF 3500 ES 3.5kVA 48V Off-Grid Solar Inverter for Home and Small Business Backup, 80A MPPT, 4.5kW PV, 450V, Parallel up to 6, IP20

UGX4,499,303
☆☆☆☆☆ No reviews yet ·Questions (0)
App price · Save UGX89,986Delivery in 7 days1-yr warranty
Christmas on SolarMarket Power for the holidays A gift that keeps the lights on. Pay safely through SolarMarket. Black Friday → Solar for every Christmas plan –Days–Hours–mins
Sold by
Masrcorp Solar Uganda ✓
Delivery in 7 days · In stock
UGX4,499,303
Ways to payAll options
Pay NowBank Transfer
Warranty and returns
Warranty
1 year · this product
Returns
7 Days · unused and not installed.
Refund
Replacement only
The warranty is this product's own (1 year). Returns and refunds follow Masrcorp Solar Uganda's signed policy. If the shop doesn't reply to a claim in 48 hours, SolarMarket steps in.
Complete your systemPick one of each. They go in your cart with this product.
Matched to 48 V
Solar PanelsUGX429,000
BatteryUGX3,334,760
Cables, mounting and protectionUGX15,939
With this product
Technicians who install this
Swipe/scroll to see more →
Key specs
Brand Growatt Model SPF 3500 ES
Rated Power 3500 VA Max PV Input Power 4500 W
Max Charging Current 60A MPPT Voltage Range 120-430 V
Nominal Output Voltage 230 Vac Nominal Output Frequency 50/60 Hz
Nominal Voltage 48 V Number of MPPT Trackers 1
Surge Power 7000 VA Product Dimensions 330 x 485 x 135 mm (W x H x D)
Product Weight 11.5 KG Waveform Pure sine wave
Efficiency 93 % Operating Temperature 0 to 55 C
Battery Type Lithium / Lead-acid Chemistry Lead-acid
Current Rating 80 A Humidity 5% to 95% Relative Humidity(Non-condensing)
Ingress Protection IP20 Input AC Voltage Range 170-280 Vac (PC mode), 90-280 Vac (appliance mode)
Input Voltage Range 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) Inverter Type Off-grid
Max AC Input Voltage 230 VAC Max PV Input Current 22 A
Max PV Short Circuit Current (per tracker) 22A Max PV Voltage (DC) 450 V
Max. AC Input/Output Apparent Power (VA) 3500VA/ 3500W Maximum Charge Power 4500W
Parallel Operation Yes, up to 6 units Permissible Altitude <2000m
Phase Single phase Protection degree,IP20
SKU SM-HYB-GRO-01197 Start Voltage 48
Storage Temperature -15°C - 60°C Transfer Time 10 ms typical, 20 ms max

Notice a wrong or outdated datasheet? Help us fix it.

About this product

Overview

Growatt SPF-3500-ES is a 3.5kW 48V hybrid inverter for Uganda power conditions. It supports up to 4.5kW PV input and is suitable for Home backup power, Small business solar, Off-grid solar where dependable backup and solar charging are required. Buyers should also confirm the datasheet limits, warranty coverage, seller authenticity, and installer compatibility before ordering

About this item

  • RATED POWER: 3.5kVA/3500W continuous output with 7kVA surge capacity for starting motors and compressors.
  • BATTERY COMPATIBILITY: Works with 48V lithium or lead-acid batteries; 60A charge current for fast recharging.
  • SOLAR INPUT: Dual MPPT tracker accepts 120-430VDC PV array, up to 4500W maximum, with 80A charge current.
  • PARALLEL OPERATION: Supports up to 6 units in parallel for scalable power up to 21kVA.
  • TRANSFER TIME: 10ms typical (20ms max) switch between grid and battery, safe for sensitive electronics.
  • PROTECTION: IP20 enclosure, wide input voltage range (90-280VAC), auto-sensing 50/60Hz frequency.

What's Included

  • Growatt SPF-3500-ES hybrid inverter unit
  • User manual
  • Mounting brackets
  • AC input/output terminals
  • PV input terminals
  • Battery connection cables (if included by seller)

Applications

  • Home backup power during grid outages
  • Small business solar systems (shops, offices, clinics)
  • Off-grid solar installations with battery storage
  • Grid-tied systems with battery backup (hybrid mode)
  • Remote monitoring stations or telecom equipment
Ask Volta about this“Will it run my fridge and pump overnight?”
Chat with Volta
Frequently Asked Questions
What are the key specs of Growatt SPF-3500-ES in Uganda?
Growatt SPF-3500-ES is a 3.5kW hybrid inverter in Uganda. Key specs include battery voltage range 48V, max PV input power 4.5kW, rated AC output 3.5kW.
What PV voltage limits should technicians use for Growatt SPF-3500-ES?
For Growatt SPF-3500-ES, use MPPT/operating voltage range 120VDC ~ 430VDC, max PV input voltage the listed max PV voltage, and max PV input power 4.5kW when designing strings.
How much solar PV can be connected to Growatt SPF-3500-ES?
Growatt SPF-3500-ES allows up to 4.5kW PV input power. Use MPPT range 120VDC ~ 430VDC for string sizing checks.
What battery and charge current settings apply to Growatt SPF-3500-ES?
Growatt SPF-3500-ES is built for 48V battery systems. The battery voltage range is 48V, with maximum charging current 80A.
What AC output should buyers and installers expect from Growatt SPF-3500-ES?
Growatt SPF-3500-ES has a rated AC output of 3.5kW. It operates with grid frequency 50Hz/60Hz (Auto sensing) and AC voltage range 230 VAC. If needed, use 230 VAC for compatibility checks.
What should buyers compare before ordering Growatt SPF-3500-ES in Uganda?
Compare verified seller pricing, warranty terms, authenticity, and installer support for Growatt SPF-3500-ES. Also match battery voltage range, MPPT layout, max PV input voltage, communication, monitoring, AC output, and warranty against the datasheet.
